PC350LC-8M0 S/N 85001-UP

Komatsu parts book diagram for PC350LC-8M0 S/N 85001-UP: FRONT IDLER AND IDLER CUSHION, IDLER(#81039-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	207-30-00693	Idler Assembly	2	SN: 81316-UP
	?	207-30-00692	Idler Assembly	2	SN: 81039-81315 \| SCC: A2
	?	207-30-48110	Idler	1	SN: 80001-UP
	?	207-30-53141	Bushing	2	SN: 81316-UP
	?	207-30-53140	Bushing	2	SN: 80001-81315 \| SCC: A2
	?	207-30-53130	Shaft	1	SN: 80001-UP
	?	07040-13618	Plug	1	SN: 80001-UP
	?	07002-13634	O-ring	1	SN: 80001-UP
	?	07000-12075	O-ring	2	SN: 80001-UP
	?	207-30-01220	Floating Seal Assembly	2	SN: 80434-UP
	?		Seal	2	SN: 80434-UP \| SCC: C1
	?		O-ring	2	SN: 80434-UP \| SCC: C1
	?	207-30-48450	Support	2	SN: 81039-UP
	?	207-30-53160	Pin	2	SN: 80001-UP
	?		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP
	?		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu PC350LC-8M0 S/N 85001-UP parts catalog PDF

FRONT IDLER AND IDLER CUSHION, IDLER(#81039-) (R0110-001001A) in PC350LC-8M0 S/N 85001-UP. Diagram image and parts list.
