PC210LCI-11E0 S/N 600001-UP

Komatsu parts book diagram for PC210LCI-11E0 S/N 600001-UP: HYDRAULIC PUMP, PISTON PUMP (9/12)(#500470-)

? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	708-2G-00320	Pump Assembly	1	SN: 500470-UP
	?	708-2G-01320	Pump Subassembly	1	SN: 500470-UP \| SCC: C2
	?	708-2G-03330	Cover Assembly, Rear	1	SN: 500470-UP \| SCC: C2
	?	708-2G-14630	Screw	1	SN: 500470-UP \| SCC: C2
	?	07000-B3038	O-ring	1	SN: 500470-UP \| SCC: C2
	?	708-2G-15230	Ring, Back-up	1	SN: 500470-UP \| SCC: C2
	?	708-2L-35290	Nut	1	SN: 500470-UP \| SCC: C2
	?	708-2G-14620	Cover	1	SN: 500470-UP \| SCC: C2
	?	07000-B2050	O-ring	1	SN: 500470-UP \| SCC: C2
	?	708-2G-15310	Ring, Back-up	1	SN: 500470-UP \| SCC: C2
	?	01010-61645	Bolt	4	SN: 500470-UP \| SCC: C2
	?	01643-31645	Washer	4	SN: 500470-UP \| SCC: C2
	?	708-2G-12630	Coupling	1	SN: 500470-UP \| SCC: C2
	?		[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu PC210LCI-11E0 S/N 600001-UP parts catalog PDF

HYDRAULIC PUMP, PISTON PUMP (9/12)(#500470-) (H0210-001009) in PC210LCI-11E0 S/N 600001-UP. Diagram image and parts list.
