PC210LCI-11E0 S/N 600001-UP

Komatsu parts book diagram for PC210LCI-11E0 S/N 600001-UP: SIDE COVER L.H., INNER PARTS, PRE-CLEANER(#510419-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	20Y-01-41350	Cleaner Assembly	1	SN: 504509-UP
	?		Hood	1	SN: 504509-UP \| SCC: C1
	?		Body	1	SN: 504509-UP \| SCC: C1
	?		Clamp	1	SN: 504509-UP \| SCC: C1
	?		Rotor	1	SN: 504509-UP \| SCC: C1
	?		Bolt	1	SN: 504509-UP \| SCC: C1
	?		Ring, Snap	2	SN: 504509-UP \| SCC: C1
	?		Bearing, Ball	2	SN: 504509-UP \| SCC: C1
	?		Bushing	2	SN: 510419-UP \| SCC: C1
	?		Bushing	1	SN: 504509-UP \| SCC: C1
	?		Shield	1	SN: 504509-UP \| SCC: C1
	?		Nut	1	SN: 504509-UP \| SCC: C1
	?		Bolt	4	SN: 504509-UP \| SCC: C1
	?		Nut	4	SN: 504509-UP \| SCC: C1
	?		Plug, Plastic	1	SN: 504509-UP \| SCC: C1
	?		Washer, Flat	1	SN: 504509-UP \| SCC: C1
	?		Shield	1	SN: 504509-UP \| SCC: C1
	?		Screw, Tapping	6	SN: 504509-UP \| SCC: C1
	?		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu PC210LCI-11E0 S/N 600001-UP parts catalog PDF

SIDE COVER L.H., INNER PARTS, PRE-CLEANER(#510419-) (M1130-005005A) in PC210LCI-11E0 S/N 600001-UP. Diagram image and parts list.
