Komatsu parts book diagram for PC290LC-8 S/N 32001-UP: SWING PIPING, (#30471-)

? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	206-62-26120	Hose	1	SN: 30471-UP
	?	07000-13025	O-ring	2	SN: 30471-UP
	?	206-62-26130	Hose	1	SN: 30471-UP
	?	07000-13025	O-ring	2	SN: 30471-UP
	?	07371-30640	Flange, Split	8	SN: 30471-UP
	?	07372-21035	Bolt	16	SN: 30471-UP
	?	01643-51032	Washer	16	SN: 30471-UP

Komatsu PC290LC-8 S/N 32001-UP parts catalog PDF

SWING PIPING, (#30471-) (H1340-001001) in PC290LC-8 S/N 32001-UP. Diagram image and parts list.
