PC290LC-8 S/N 32001-UP

Komatsu parts book diagram for PC290LC-8 S/N 32001-UP: REAR UNDER VIEW MIRROR, (#30471-)

? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	207-54-75711	Mirror	1	SN: 30719-UP
	?	207-54-75710	Mirror	1	SN: 30471-30718 \| SCC: A2
	?	20Y-54-74311	Bracket	1	SN: 30471-UP
	?	01010-81230	Bolt	2	SN: 30471-UP
	?	01643-31232	Washer	2	SN: 30471-UP
	?		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP

Komatsu PC290LC-8 S/N 32001-UP parts catalog PDF

REAR UNDER VIEW MIRROR, (#30471-) (M1430-001001) in PC290LC-8 S/N 32001-UP. Diagram image and parts list.
