02 |
907 565 40
|
Fluid level indicator with swimming ball inclusive fig.no. 41 a. 42 450 mm lg. |
2 |
|
|
|
|
03 |
906 925 40
|
Union |
2 |
|
|
|
|
04 |
519 388 98
|
Hose assy., with fire protection coating, DN 20x2140 |
1 |
|
|
|
|
05 |
518 231 98
|
Hose assy., with fire protection coating, DN 16x650 |
2 |
|
|
|
|
06 |
518 029 98
|
Hose assy., with fire protection coating, DN 16x450 |
2 |
|
|
|
|
07 |
519 682 98
|
Hose assy., with fire protection coating, DN 20x2600 |
1 |
|
|
|
|
08 |
518 208 98
|
Hose assy., with fire protection coating, DN 20x3000 |
2 |
|
|
|
|
09 |
518 408 98
|
Hose assy., with fire protection coating, DN 20x3500 |
1 |
|
|
|
|
10 |
374 409 99
|
Socket |
4 |
|
|
|
|
11 |
516 160 98
|
Socket |
6 |
|
|
|
|
12 |
518 984 98
|
Hose assy. DN 20x1670 |
1 |
|
|
|
|
13 |
519 062 98
|
Hose assy., with fire protection coating, DN 20x2350 |
1 |
|
|
|
|
14 |
654 892 40
|
Union |
6 |
|
|
|
|
15 |
551 404 40
|
Socket |
2 |
|
|
|
|
16 |
907 321 40
|
Union |
4 |
|
|
|
|
17 |
655 294 40
|
Union |
2 |
|
|
|
|
18 |
307 800 99
|
Bolt |
8 |
|
|
|
|
19 |
518 200 98
|
Lock washer |
12 |
|
|
|
|
20 |
504 789 98
|
Catch |
8 |
|
|
|
|
21 |
534 004 99
|
Cover plate |
18 |
|
|
|
|
22 |
517 122 98
|
Lock washer |
36 |
|
|
|
|
23 |
518 042 98
|
Clamp Set |
18 |
|
|
|
|
24 |
308 581 99
|
Bolt |
36 |
|
|
|
|
25 |
517 599 98
|
Socket |
4 |
|
|
|
|
26 |
634 298 40
|
Socket |
4 |
|
|
|
|
27 |
504 788 98
|
Screw |
16 |
|
|
|
|
28 |
323 460 40
|
Bleeder valve |
2 |
|
|
|
|
29 |
621 626 40
|
Sleeve |
2 |
|
|
|
|
30 |
906 982 40
|
Union |
2 |
|
|
|
|
31 |
339 907 99
|
Seal ring |
4 |
|
|
|
|
32 |
509 060 98
|
Clamp Set |
2 |
|
|
|
|
33 |
511 858 98
|
Cover plate |
2 |
|
|
|
|
34 |
308 542 99
|
Bolt |
4 |
|
|
|
|
35 |
517 120 98
|
Lock washer |
4 |
|
|
|
|
36 |
308 604 99
|
Bolt |
4 |
|
|
|
|
37 |
519 661 98
|
Hose assy., with fire protection coating, DN 20x1680 |
1 |
|
|
|
|
38 |
518 209 98
|
Hose assy., with fire protection coating, DN 20x3850 |
1 |
|
|
|
|
39 |
519 681 98
|
Hose assy., with fire protection coating, DN 20x1900 |
1 |
|
|
|
|
40 |
504 643 98
|
Union |
-2 |
|
|
|
|
41 |
516 824 98
|
Union |
-2 |
|
|
|
|
45 |
|
Oilmanagement System |
1 |
|
|
|
|
45 |
|
Oilmanagement System, without Centinel |
1 |
|
|
|
|
46 |
792 330 73
|
Sludge Collecting Paper |
20 |
|
|
|
|
49 |
768 441 73
|
Bypass filter (Diesel Engine) |
4 |
|
|
|
|
50 |
770 563 73
|
Pump |
1 |
|
|
|
|
61 |
972 099
|
O-ring |
4 |
|
|
|
|
62 |
511 602 98
|
Banjo bolt |
4 |
|
|
|
|
|$$48 |
|
|
-2 |
|
|
|
|
|$$49 |
|
|
-2 |
|
|
|
|
|$$50 |
|
|
-2 |
|
|
|
|
|$$51 |
|
|
-2 |
|
|
|
|
|$$52 |
|
|
-2 |
|
|
|
|
|$$53 |
|
|
-2 |
|
|
