Komatsu parts book diagram for PC220LCi-12 S/N A15001: R1200-001001 TRACK ROLLER GUARD (FULL LENGTH)

? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	20Y-30-35171	GUARD	2
	?	20Y-30-35181	GUARD	2
	?	01010-62050	BOLT	32
	?	01643-32060	WASHER	32
	?	09205-18295	BOLT	18
	?	01643-31845	WASHER	36
	?	01580-11815	NUT	18
	?	20Y-30-23140	COLLAR	18

Komatsu PC220LCi-12 S/N A15001 parts catalog PDF

R1200-001001 TRACK ROLLER GUARD (FULL LENGTH) (R1200-001001) in PC220LCi-12 S/N A15001. Diagram image and parts list.
