58F-32-50072
|
SPINDLE, HUB AND BRAKE ASSEMBLY |
1 |
|
|
|
|
? |
EH7195
|
O-RING (1) |
1 |
|
|
|
|
? |
EJ7475
|
GEAR, SPEED SENSOR |
1 |
|
|
|
|
? |
58F-32-00202
|
SPINDLE |
1 |
|
|
|
|
? |
PC3059
|
BEARING ASSEMBLY, INNER (1) |
1 |
|
|
|
|
? |
562-22-32290
|
PIN (1) |
2 |
|
|
|
|
? |
ED3772
|
SPACER, BEARING |
1 |
|
|
|
|
? |
EH7194
|
O-RING (1) |
1 |
|
|
|
|
? |
EH7196
|
O-RING (1) |
1 |
|
|
|
|
? |
ED3775
|
ADAPTER, BRAKE |
1 |
|
|
|
|
? |
58F-32-50010
|
FRONT BRAKE ASSEMBLY (SEE FIG 65352) |
1 |
|
65352 |
|
|
? |
569-33-81241
|
ADAPTER |
1 |
|
|
|
|
? |
58C-32-00452
|
TANK, CATCHMENT |
1 |
|
|
|
|
? |
07002-52034
|
O-RING (1) |
1 |
|
|
|
|
? |
58F-32-40110
|
SEAL ASSEMBLY, FLOATING (2) |
1 |
|
|
|
|
? |
PC1431
|
SEAL, OIL (1)/(2) |
1 |
|
|
|
|
? |
58F-32-40030
|
CARRIER, SEAL |
1 |
|
|
|
|
? |
58F-32-40051
|
BRACKET, MOUNTING |
6 |
|
|
|
|
? |
58F-32-50030
|
SEAL ASSEMBLY, FLOATING (1) |
1 |
|
|
|
|
? |
58F-32-00161
|
CARRIER, FLOATING SEAL |
1 |
|
|
|
|
? |
WA4780
|
PLUG, O-RING |
2 |
|
|
|
|
? |
58F-22-00850
|
VENT, BREATHER (1) |
2 |
|
|
|
|
? |
07000-52018
|
O-RING (1) |
1 |
|
|
|
|
? |
58F-32-00180
|
O-RING (1) |
1 |
|
|
|
|
? |
D2930
|
CAPSCREW, SOCKET HEAD - 1/2" - 13NC X 3/4" |
6 |
|
|
|
|
? |
C1612
|
CAPSCREW - 1/2" - 13NC X 1" |
12 |
|
|
|
|
? |
C1613
|
CAPSCREW - 1/2" - 13NC X 1 1/4" |
4 |
|
|
|
|
? |
DF6928
|
CAPSCREW - 1/2" - 13NC X 1 3/4" |
8 |
|
|
|
|
? |
WA0360
|
FLAT WASHER, HARDENED - 1/2" |
28 |
|
|
|
|
? |
WA5669
|
CAPSCREW, 12 PT - 1 1/4" - 12NF X 3 1/2" |
57 |
|
|
|
|
? |
WB1231
|
CAPSCREW - 1 1/4" - 12NF X 8" |
32 |
|
|
|
|
? |
58B-09-50080
|
FLAT WASHER, HARDENED - 1 1/4" |
75 |
|
|
|
|
? |
H8402
|
PLUG - 3/8" |
1 |
|
|
|
|
? |
|
|
-1 |
|
|
|
|
? |
58F-SM-AK110
|
NOTE: (1) INCLUDED IN 58F-SM-AK110 SPINDLE |
-1 |
|
|
|
|
? |
|
MAINTENANCE KIT. BALANCE OF PARTS ON PREVIOUS PAGE. |
-1 |
|
|
|
|
? |
58F-BK-AK071
|
(2) INCLUDED IN 58F-BK-AK071 FRONT BRAKE |
-1 |
|
|
|
|
? |
|
SEAL KIT. |
-1 |
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
-1 |
|
|
