COVERING - ENGINE HOUSING | PC3000-6 S/N 46230 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
02	939 251 40	Post 1	1
03	939 252 40	Post 2	1
04	939 253 40	Post 3	1
05	939 257 40	Post 7	1
06	939 255 40	Post 5	1
07	939 296 40	Post 6	1
08	939 254 40	Post 4	1
09	939 212 40	Wall	1
10	946 158 40	Door	1
11	940 906 40	Fastener with out lock pin consist. of fig nos 100-106	1
12	940 907 40	Fastener with out lock pin consist. of fig nos 100-105, 107	1
13	517 122 98	Lock washer	4
14	930 550 40	Wall	1
15	946 171 40	Door, radiator	1
16	927 264 40	Wall	1
17	946 165 40	Hinge	5
18	946 151 40	Hinge	2
19	939 282 40	Door	1
20	946 170 40	Door	1
21	949 385 40	Cotter pin	1
22	934 342 40	Angle	1
23	934 343 40	Angle	1
24	167 693 40	Flex. Header	-2
25	954 604 40	Plate	1
26	510 741 98	Resilient sleeve	9
27	308 608 99	Bolt	9
28	510 732 98	Resilient sleeve	28
29	308 885 99	Bolt to fig-nos. 02, 06-08	16
30	308 414 99	Bolt to fig-nos. 03, 04 + 05	12
31	927 230 40	Pipe	2
32	307 805 99	Bolt	8
33	081 282 40	Round buffer	1
34	513 252 98	Screw	1
35	307 779 99	Bolt	2
36	308 610 99	Bolt	28
37	334 600 99	Nut	45
38	340 467 99	Washer	46
39	939 280 40	Cotter pin	1
40	939 281 40	Plate	1
41	307 802 99	Bolt	4
42	307 802 99	Bolt	19
43	340 510 99	Washer	1
44	592 259 40	Profiled joint	-2
45	517 118 98	Lock washer	29
46	946 164 40	Hinge	2
47	307 780 99	Bolt	10
48	340 007 99	Washer	16
49	507 037 98	Nut	8
50	946 192 40	Plate	1
52	517 122 98	Lock washer	6
53	307 773 99	Bolt	6
54	440 821 40	Rubber	-2
55	307 804 99	Bolt	6
60	919 943 40	Roof section 1	1
61	925 753 40	Roof section 2	1
61	936 564 40	Roof section 2 (with emergency exit)	1
62	925 754 40	Roof section 3	1
63	925 755 40	Roof section 4	1
64	510 741 98	Resilient sleeve	45
65	308 608 99	Bolt	45
66	307 949 99	Bolt	5
67	517 118 98	Lock washer	8
68	598 248 40	Threaded rail	2
69	598 250 40	Threaded rail	2
70	598 249 40	Threaded rail	1
71	598 240 40	Threaded rail	2
72	598 239 40	Threaded rail	4
73	180 894 40	Plug	16
74	930 529 40	Cover	1
75	517 122 98	Lock washer	4
76	507 037 98	Nut	2
77	930 516 40	Plate	1
78	930 517 40	Plate	1
79	510 748 98	Resilient sleeve	3
80	340 467 99	Washer	7
81	307 807 99	Bolt	3
82	307 804 99	Bolt	7
83	334 600 99	Nut	4
84	948 275 40	Angle	1
85	953 238 40	Plate	1
86	953 227 40	Threaded rail	1
87	307 775 99	Bolt	2
90	919 949 40	Roof frame	1
91	180 889 40	Plug	4
92	930 569 40	Retainer	1
93	318 603 99	Screw	2
94	517 120 98	Lock washer	2
95	308 356 99	Bolt	7
100	941 444 40	Handle	2
101	941 445 40	Handle	2
102	941 563 40	Axle	2
103	941 447 40	Collar	2
104	941 450 40	Closing cam	2
105	941 451 40	Collar	2
106	941 448 40	Accessory l.h.	1
107	941 449 40	Accessory r.h.	1
