BOOM - CENTRAL LUBRICATION BH - 8.6 M | PC3000-6 S/N 46235

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Reference
01		Metering valve	2	991-0091
02	654 130 40	Protection cap with o-ring	8
03	655 649 40	Protection hose DN 10	-2
04	374 428 99	Union	4
05	517 291 98	Union	4
06	512 273 98	Socket	2
07	936 979 40	Plate	2
08	308 555 99	Bold	4
09	515 029 40	Hose connection 90°	12
10	515 027 40	Hose connection	4
11	906 984 40	Union	1
12	324 672 40	Plug	1
13	576 160 40	Hose DN 4	-2
14	374 443 99	Union	4
15	516 834 98	Union	1
16	906 981 40	Union	8
17	515 951 98	Union	1
18	0443551210	Clip	30
19	534 000 99	Clamp Set	6
20	534 001 99	Cover plate	6
21	0443451210	Clip d=12 double	28
22	534 002 99	Weld-on plate	6
23	517 121 98	Washer	4
24	507 037 98	Nut	50
25	006 303 98	Clamp 22/15	10
26	308 579 99	Bolt	12
27	907 854 40	Thread pin	50
28	509 308 98	Locking plate	6
29	515 028 40	Collet	16
30	516 741 98	Union	2
31	371 867 99	Breech block	2
32	651 255 40	Clamp set	2
33	634 978 40	Cover plate	2
34	512 055 98	Thread pin	2
35	911 862 40	Pipe assy. Ш 25	1
36	911 863 40	Pipe assy. Ш 25	1
37	911 864 40	Pipe assy. Ш 25	1
38	215 787 99	Pipe assy. Ш25, 140 lang	-2
39	334 600 99	Nut	2
40	907 080 40	Olive	16
41	371 257 99	Union Nut	8
42	906 347 40	Olive	3
43	371 259 99	Union Nut	3
44	906 868 40	Olive	11
45	371 264 99	Union Nut	11
46	371 271 99	Union Nut	8
48	504 445 98	Clamp set	2
49	534 008 99	Cover plate	2
50	534 009 99	Weld on plate	2
51	308 612 99	Bolt	4
52	509 310 98	Locking plate	2
53	340 111 99	Washer	50
54	340 465 99	Washer	50
\|$$54			-2
\|$$55			-2
\|$$56			-2
\|$$57			-2
\|$$58			-2
\|$$59			-2
