PC200-8M0 S/N Y201001-UP

Komatsu parts book diagram for PC200-8M0 S/N Y201001-UP: AIR CLEANER

8 2 4 1 7 7 3 8 6 5

	#	Part Number	Partname	Quantity	Options	Reference
	\|$1	6754817300	AIR CLEANER ASSEMBLY	1	Field_2: 26594007 \| Field_5: 1 \| Field_6: X160B00270 \| Field_7: AIR CLEANER
	1	6001841420	COVER	1	Field_2: 26594007 \| Field_5: 2 \| Field_6: X160B00270 \| Field_7: AIR CLEANER
	\|$3	6001854100	ELEMENT ASSEMBLY	1	Field_2: 26594007 \| Field_5: 3 \| Field_6: X160B00270 \| Field_7: AIR CLEANER
	2	6001854110	ELEMENT{OUTER}	1	Field_2: 26594007 \| Field_5: 4 \| Field_6: X160B00270 \| Field_7: AIR CLEANER
	3		ELEMENT{INNER}	1	Field_2: 26594007 \| Field_4: C1 \| Field_5: 5 \| Field_6: X160B00270 \| Field_7: AIR CLEANER
	4	6001841470	ORING	1	Field_2: 26594007 \| Field_5: 6 \| Field_6: X160B00270 \| Field_7: AIR CLEANER
	5	6001841350	VALVE{VACUATOR}	1	Field_2: 26594007 \| Field_5: 7 \| Field_6: X160B00270 \| Field_7: AIR CLEANER
	6	6001811930	PLATE,SERVICE INSTRUCTION,AIR CLEANER	1	Field_2: 26594007 \| Field_5: 8 \| Field_6: X160B00270 \| Field_7: AIR CLEANER
	7	6222817190	BAND	2	Field_2: 26594007 \| Field_5: 9 \| Field_6: X160B00270 \| Field_7: AIR CLEANER
	8	6643114641	BOLT	2	Field_2: 26594007 \| Field_5: 10 \| Field_6: X160B00270 \| Field_7: AIR CLEANER

Komatsu PC200-8M0 S/N Y201001-UP parts catalog PDF

AIR CLEANER (|AA00013) in PC200-8M0 S/N Y201001-UP. Diagram image and parts list.
