SAA6D140E-7 S/N 830235-UP (For WA500-8E0)

1 2 3 8 4 5 6 5 6 6 7

#	Part Number	Partname	Quantity	Options
\|$0	6261-31-1200	Crankshaft Assembly	1	SN: 830235-UP
1		Crankshaft	1	SN: 830235-UP \| SCC: C1
2	6150-31-1130	Key	1	SN: 830235-UP
3	6210-31-1120	Gear	1	SN: 830235-UP
\|$4	6263-21-8000	Metal Assembly	1	SN: 830235-UP
\|$5	6210-21-8010	Main Metal Assembly, Standard	7	SN: 830235-UP
\|$6	6210-29-8010	Main Metal Assembly, Undersize, 0.25mm	7	SN: 830235-UP
\|$7	6210-28-8010	Main Metal Assembly, Undersize, 0.50mm	7	SN: 830235-UP
\|$8	6210-27-8010	Main Metal Assembly, Undersize, 0.75mm	7	SN: 830235-UP
\|$9	6210-26-8010	Main Metal Assembly, Undersize, 1.00mm	7	SN: 830235-UP
4		Metal, Upper, Standard	1	SN: 830235-UP \| SCC: C1
\|$11		Metal, Upper, Undersize, 0.25mm	1	SN: 830235-UP \| SCC: C1
\|$12		Metal, Upper, Undersize, 0.50mm	1	SN: 830235-UP \| SCC: C1
\|$13		Metal, Upper, Undersize, 0.75mm	1	SN: 830235-UP \| SCC: C1
\|$14		Metal, Upper, Undersize, 1.00mm	1	SN: 830235-UP \| SCC: C1
5		Metal, Lower, Standard	1	SN: 830235-UP \| SCC: C1
\|$16		Metal, Lower, Undersize, 0.25mm	1	SN: 830235-UP \| SCC: C1
\|$17		Metal, Lower, Undersize, 0.50mm	1	SN: 830235-UP \| SCC: C1
\|$18		Metal, Lower, Undersize, 0.75mm	1	SN: 830235-UP \| SCC: C1
\|$19		Metal, Lower, Undersize, 1.00mm	1	SN: 830235-UP \| SCC: C1
\|$20	6263-21-8050	Thrust Metal Assembly	1	SN: 830235-UP
\|$21	6263-29-8050	Thrust Metal Assembly, Undersize, 0.25mm	1	SN: 830235-UP
\|$22	6263-28-8050	Thrust Metal Assembly, Undersize, 0.50mm	1	SN: 830235-UP
\|$23	6263-27-8050	Thrust Metal Assembly, Undersize, 0.75mm	1	SN: 830235-UP
\|$24	6263-26-8050	Thrust Metal Assembly, Undersize, 1.00mm	1	SN: 830235-UP
6		Metal, Standard	3	SN: 830235-UP \| SCC: C1
\|$26		Metal, Undersize, 0.25mm	3	SN: 830235-UP \| SCC: C1
\|$27		Metal, Undersize, 0.50mm	3	SN: 830235-UP \| SCC: C1
\|$28		Metal, Undersize, 0.75mm	3	SN: 830235-UP \| SCC: C1
\|$29		Metal, Undersize, 1.00mm	3	SN: 830235-UP \| SCC: C1
7	04020-01228	Pin, Dowel	1	SN: 830235-UP
8	6211-31-1420	Pin	1	SN: 830235-UP

Komatsu SAA6D140E-7 S/N 830235-UP (For WA500-8E0) parts catalog PDF

CRANKSHAFT (#830235-) (A2310-001001) in SAA6D140E-7 S/N 830235-UP (For WA500-8E0). Diagram image and parts list.
