SAA6D125E-7 S/N 865972-UP (For WA475-10E0)

5 6 6 5 3 4 1 2 6

#	Part Number	Partname	Quantity	Options
\|$0	6252-31-1010	Crankshaft Assembly	1	SN: 865972-UP
1		Crankshaft	1	SN: 865972-UP \| SCC: C1
2	6150-35-1120	Gear	1	SN: 865972-UP
3	6150-31-1130	Key	1	SN: 865972-UP
\|$4	6150-21-8010	Main Metal Assembly, Standard	7	SN: 865972-UP
\|$5	6150-29-8010	Main Metal Assembly, Undersize, 0.25mm	7	SN: 865972-UP
\|$6	6150-28-8010	Main Metal Assembly, Undersize, 0.50mm	7	SN: 865972-UP
\|$7	6150-27-8010	Main Metal Assembly, Undersize, 0.75mm	7	SN: 865972-UP
\|$8	6150-26-8010	Main Metal Assembly, Undersize, 1.00mm	7	SN: 865972-UP
4		Metal, Upper, Standard	1	SN: 865972-UP \| SCC: C1
\|$10		Metal, Upper, Undersize, 0.25mm	1	SN: 865972-UP \| SCC: C1
\|$11		Metal, Upper, Undersize, 0.50mm	1	SN: 865972-UP \| SCC: C1
\|$12		Metal, Upper, Undersize, 0.75mm	1	SN: 865972-UP \| SCC: C1
\|$13		Metal, Upper, Undersize, 1.00mm	1	SN: 865972-UP \| SCC: C1
5		Metal, Lower, Standard	1	SN: 865972-UP \| SCC: C1
\|$15		Metal, Lower, Undersize, 0.25mm	1	SN: 865972-UP \| SCC: C1
\|$16		Metal, Lower, Undersize, 0.50mm	1	SN: 865972-UP \| SCC: C1
\|$17		Metal, Lower, Undersize, 0.75mm	1	SN: 865972-UP \| SCC: C1
\|$18		Metal, Lower, Undersize, 1.00mm	1	SN: 865972-UP \| SCC: C1
\|$19	6150-21-8050	Thrust Metal Assembly, Standard	1	SN: 865972-UP
\|$20	6150-29-8050	Thrust Metal Assembly, Undersize, 0.25mm	1	SN: 865972-UP
\|$21	6150-28-8050	Thrust Metal Assembly, Undersize, 0.50mm	1	SN: 865972-UP
\|$22	6150-27-8050	Thrust Metal Assembly, Undersize, 0.75mm	1	SN: 865972-UP
\|$23	6150-26-8050	Thrust Metal Assembly, Undersize, 1.00mm	1	SN: 865972-UP
6		Metal, Thrust,Standard	3	SN: 865972-UP \| SCC: C1
\|$25		Metal, Thrust, Undersize, 0.25mm	3	SN: 865972-UP \| SCC: C1
\|$26		Metal, Thrust, Undersize, 0.50mm	3	SN: 865972-UP \| SCC: C1
\|$27		Metal, Thrust, Undersize, 0.75mm	3	SN: 865972-UP \| SCC: C1
\|$28		Metal, Thrust, Undersize, 1.00mm	3	SN: 865972-UP \| SCC: C1

Komatsu SAA6D125E-7 S/N 865972-UP (For WA475-10E0) parts catalog PDF

CRANKSHAFT (#865972-) (A2310-001001) in SAA6D125E-7 S/N 865972-UP (For WA475-10E0). Diagram image and parts list.
