1 |
6252-31-2110
|
Piston |
6 |
SN: 865972-UP
|
|
|
|
2 |
6151-31-2410
|
Pin |
6 |
SN: 865972-UP
|
|
|
|
3 |
04065-04818
|
Ring, Snap |
12 |
SN: 865972-UP
|
|
|
|
|$3 |
6252-31-2030
|
Ring Assembly, Piston |
6 |
SN: 865972-UP
|
|
|
|
4 |
|
Ring, Top |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
5 |
|
Ring, Second |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
6 |
|
Ring, Oil |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
|$7 |
6251-31-3100
|
Connecting Rod Assembly |
6 |
SN: 865972-UP
|
|
|
|
7 |
|
Rod, Connecting |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
8 |
|
Cap, Connecting Rod |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
9 |
6251-31-3130
|
Bushing |
1 |
SN: 865972-UP | SCC: C3
|
|
|
|
10 |
6150-31-3310
|
Bolt |
2 |
SN: 865972-UP
|
|
|
|
11 |
02400-10413
|
Pin, Dowel |
2 |
SN: 865972-UP
|
|
|
|
|$13 |
6151-31-3050
|
Metal Assembly, Standard |
6 |
SN: 865972-UP
|
|
|
|
|$14 |
6151-39-3050
|
Metal Assembly, Undersize, 0.25mm |
6 |
SN: 865972-UP
|
|
|
|
|$15 |
6151-38-3050
|
Metal Assembly, Undersize, 0.50mm |
6 |
SN: 865972-UP
|
|
|
|
|$16 |
6151-37-3050
|
Metal Assembly, Undersize, 0.75mm |
6 |
SN: 865972-UP
|
|
|
|
|$17 |
6151-36-3050
|
Metal Assembly, Undersize, 1.00mm |
6 |
SN: 865972-UP
|
|
|
|
12 |
|
Metal, Upper, Standard |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
|$19 |
|
Metal, Upper, Undersize, 0.25mm |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
|$20 |
|
Metal, Upper, Undersize, 0.50mm |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
|$21 |
|
Metal, Upper, Undersize, 0.75mm |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
|$22 |
|
Metal, Upper, Undersize, 1.00mm |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
13 |
|
Metal, Lower, Standard |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
|$24 |
|
Metal, Lower, Undersize, 0.25mm |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
|$25 |
|
Metal, Lower, Undersize, 0.50mm |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
|$26 |
|
Metal, Lower, Undersize, 0.75mm |
1 |
SN: 865972-UP | SCC: C1
|
|
|
|
|$27 |
|
Metal, Lower, Undersize, 1.00mm |
1 |
SN: 865972-UP | SCC: C1
|
|
