01 |
956 078 40
|
Harness - Engine |
1 |
|
|
|
|
03 |
963 883 40
|
Retainer |
2 |
|
|
|
|
04 |
414 899 40
|
Rpm-sensor |
1 |
|
|
|
|
05 |
0443451210
|
Clamp Ш12 |
13 |
|
|
|
|
06 |
0443451510
|
Clamp Ш15 |
15 |
|
|
|
|
07 |
0443453211
|
Clamp Ш32 |
10 |
|
|
|
|
08 |
0443452711
|
Clamp Ш27 |
5 |
|
|
|
|
10 |
0819320010
|
Clip |
36 |
|
|
|
|
11 |
307 779 99
|
Bolt |
24 |
|
|
|
|
12 |
507 037 98
|
Nut |
66 |
|
|
|
|
13 |
340 465 99
|
Washer |
66 |
|
|
|
|
14 |
518 594 98
|
Lock washer |
24 |
|
|
|
|
15 |
502 313 98
|
Bolt |
7 |
|
|
|
|
16 |
516 142 98
|
Resilient sleeve |
4 |
|
|
|
|
17 |
307 782 99
|
Bolt |
4 |
|
|
|
|
18 |
518 080 98
|
Resilent sleeve |
16 |
|
|
|
|
19 |
307 775 99
|
Bolt |
3 |
|
|
|
|
20 |
518 547 98
|
Lock washer |
9 |
|
|
|
|
21 |
507 596 98
|
Washer |
30 |
|
|
|
|
22 |
957 073 40
|
Angle |
2 |
|
|
|
|
23 |
963 734 40
|
Cover |
1 |
|
|
|
|
25 |
963 859 40
|
Harness Generator 52G005 - / 52GND |
1 |
|
|
|
|
26 |
972 007 40
|
Cable starter 52M001+/71X_71 |
1 |
|
|
|
|
27 |
963 848 40
|
Harness 52GND / 60GND |
1 |
|
|
|
|
28 |
963 857 40
|
Cable starter 52M001-/71X_71 |
1 |
|
|
|
|
29 |
972 004 40
|
Cable generator 52G005/71X_71 |
1 |
|
|
|
|
30 |
963 856 40
|
Cable starter 52M001-/71Q004 |
1 |
|
|
|
|
31 |
963 851 40
|
Cable starter 52M001+/71X_71 |
1 |
|
|
|
|
32 |
990 651 40
|
Harness 11X_52.034 - 52Q002A.30 |
1 |
|
|
|
|
34 |
963 884 40
|
Retainer |
1 |
|
|
|
|
35 |
907 371 40
|
Sealing profile |
1 |
|
|
|
|
36 |
963 710 40
|
Harness Amplifier 14X252/14X352 |
1 |
|
|
|
|
37 |
963 708 40
|
Harness - Komtrax+ exhaust right |
1 |
|
|
|
|
38 |
963 709 40
|
Harness - Komtrax+ exhaust left |
1 |
|
|
|
|
39 |
963 894 40
|
Amplifier |
1 |
|
|
|
|
40 |
0443451910
|
Clamp Ш19 |
5 |
|
|
|
|
41 |
519 162 98
|
Resilient sleeve |
10 |
|
|
|
|
42 |
519 161 98
|
Screw |
10 |
|
|
|
|
43 |
963 897 40
|
Harness - Fuel filter |
1 |
|
|
|
|
44 |
0443450810
|
Clamp Ш8 |
8 |
|
|
|
|
45 |
977 522 40
|
Retainer |
2 |
|
|
|
|
46 |
977 523 40
|
Retainer |
1 |
|
|
|
|
47 |
0443450510
|
Clamp Ш4.8 |
1 |
|
|
|
|
48 |
307 777 99
|
Bolt |
1 |
|
|
|
|
49 |
307 780 99
|
Bolt |
2 |
|
|
|
|
52 |
941 405 40
|
Plug assy. |
1 |
|
|
|
|
53 |
941 406 40
|
Plug assy. |
1 |
|
|
|
|
54 |
906 516 40
|
Female contact 1-8 gold |
7 |
|
|
|
|
55 |
255 745 40
|
Rubber grommet |
7 |
|
|
|
|
56 |
896 522 40
|
End pin |
1 |
|
|
|
|
57 |
896 520 40
|
End pin |
32 |
|
|
|
|
58 |
896 521 40
|
End pin |
5 |
|
|
|
|
59 |
950 189 40
|
Plug |
3 |
|
|
|
|
60 |
950 190 40
|
Rubber grommet |
5 |
|
|
|
|
65 |
975 586 40
|
Plug assy. |
1 |
|
|
|
|
66 |
950 132 40
|
Protection cap |
4 |
|
|
|
|
67 |
941 777 40
|
Plate |
13 |
|
|
|
|
68 |
634 968 40
|
Cable strap |
3 |
|
|
|
|
69 |
950 802 40
|
Body Plug |
1 |
|
|
|
|
70 |
055 108 40
|
Cable lug |
7 |
|
|
|
|
71 |
950 112 40
|
Plug |
1 |
|
|
|
|
72 |
950 105 40
|
Plug |
1 |
|
|
|
|
73 |
0819105320
|
Pin contact |
16 |
|
|
|
|
74 |
0819100770
|
Sealing plug |
14 |
|
|
|
|
75 |
0819105340
|
Pin contact |
10 |
|
|
|
|
76 |
941 407 40
|
Plug assy. |
1 |
|
|
|
|
77 |
056 057 40
|
Cable sleeve |
3 |
|
|
|
|
78 |
940 852 40
|
Plug |
58 |
|
|
|
|
79 |
950 801 40
|
Plug |
1 |
|
|
|
|
80 |
951 510 40
|
Female contact |
8 |
|
|
|
|
81 |
941 408 40
|
End cup |
3 |
|
|
|
|
82 |
174 411 40
|
Cable strap |
26 |
|
|
|
|
83 |
960 642 40
|
Socket assy. with protective housing |
1 |
|
|
|
|
84 |
963 879 40
|
Relay plate |
1 |
|
|
|
|
85 |
963 881 40
|
Harness prelub relay |
1 |
|
|
|
|
86 |
990 650 40
|
Harness starter relay T2 |
1 |
|
|
|
|
87 |
972 012 40
|
Harness 52Q002A.31 / 52Q030A.85 |
1 |
|
|
|
|
89 |
950 802 40
|
Body Plug |
1 |
|
|
|
|
90 |
907 959 40
|
Plug sleeve |
1 |
|
|
|
|
91 |
950 190 40
|
Rubber grommet |
1 |
|
|
|
|
93 |
056 076 40
|
Protection cap |
13 |
|
|
|
|
94 |
932 727 40
|
Cable lug Ш 6 -70 |
1 |
|
|
|
|
95 |
600 208 99
|
Cable lug Ш 10 -70 |
4 |
|
|
|
|
96 |
655 693 40
|
End grommet |
12 |
|
|
|
|
97 |
600 221 99
|
Cable lug Ш 10 -120 |
2 |
|
|
|
|
98 |
932 728 40
|
Cable lug Ш 8 -70 |
1 |
|
|
|
|
99 |
950 110 40
|
Plug |
2 |
|
|
|
|
100 |
950 443 40
|
Socket assy. with rubber grommet |
12 |
|
|
|
|
101 |
941 416 40
|
Connector Female |
12 |
|
|
|
|
102 |
907 709 40
|
Cable union PG 16 |
12 |
|
|
|
|
103 |
972 021 40
|
Retainer |
1 |
|
|
|
|
104 |
517 180 98
|
Screw |
24 |
|
|
|
|
105 |
517 120 98
|
Lock washer |
24 |
|
|
|
|
106 |
332 110 99
|
Nut |
24 |
|
|
|
|
107 |
6215818152
|
Amplifier |
12 |
|
|
|
|
108 |
958 963 40
|
Socket assy. with rubber grommet |
2 |
|
|
|
|
109 |
941 609 40
|
Cable 1.5mm2 |
-2 |
|
|
|
|
110 |
950 190 40
|
Rubber grommet |
12 |
|
|
|
|
111 |
907 553 40
|
Cable 16.0mm2 |
-2 |
|
|
|
|
112 |
941 354 40
|
Cable lug Ш 5 - 16 |
2 |
|
|
|
|
113 |
255 745 40
|
Rubber grommet |
6 |
|
|
|
|
115 |
055 108 40
|
Cable lug Ш 5 - 2.5 |
3 |
|
|
|
|
116 |
256 947 40
|
Cable lug Ш 8 - 16 |
2 |
|
|
|
|
117 |
907 511 40
|
Cable lug 2,5 |
1 |
|
|
|
|
118 |
941 880 40
|
Plug |
12 |
|
|
|
|
119 |
941 791 40
|
Rubber grommet |
12 |
|
|
|
|
120 |
256 947 40
|
Cable lug |
1 |
|
|
|
|
121 |
255 745 40
|
Rubber grommet |
1 |
|
|
|
|
122 |
269 078 40
|
Wire end ferrule |
1 |
|
|
|
|
124 |
952 675 40
|
Plug assy. with rubber grommet |
2 |
|
|
|
|
126 |
977 530 40
|
Harness 52GND - 52G006. |
1 |
|
|
|
|
127 |
977 529 40
|
Harness 52Q030A.30G-52G006. |
1 |
|
|
|
|
128 |
977 531 40
|
Harness 52M002-1.BAT-52Q030A |
1 |
|
|
|
|
161 |
990 648 40
|
Harness 52M001-1 / 52Q002A.30G |
1 |
|
|
|
|
163 |
972 013 40
|
Harness 52M002-1 / 52Q002A.31 |
1 |
|
|
|
|
164 |
990 649 40
|
Harness 52M002-1 / 52Q002A.30G |
1 |
|
|
