Diagram image 1 of 2

PC3000-6 S/N 06330

? ? ? ? ?

PC3000-6 S/N 06330

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	959 576 40	Cab support	1
?	922 856 40	Cover	1
?	946 028 40	Cover	1
?	323 315 40	Grating	1
?	930 919 40	Grating	1
?	959 571 40	Grating	1
?	317 319 40	Threaded block	18
?	317 318 40	Wing nut, plastic	13
?	334 599 99	Nut	8
?	340 507 99	Washer	8
?	502 354 98	Bolt	13
?	340 465 99	Washer	4
?	507 037 98	Nut	4
?	904 244 40	Cover	1
?	307 805 99	Bolt	6
?	517 118 98	Lock washer	6
?	592 259 40	Profiled joint 5000 mm lg	-2
?	946 195 40	Door, incl. fig-nos: 31-37	1
?	390 199 40	Hinge, incl. fig-nos: 41-46	6
?	507 037 98	Nut	3
?	307 779 99	Bolt	4
?	959 545 40		2
?	332 353 99	Nut	4
?	334 600 99	Nut	4
?	500 873 98	Bolt	4
?	517 118 98	Lock washer	4
?	946 184 40	Yoke	1
?	342 057 99	Split pin	1
?	975 111 40	Edge plate	1
?	340 465 99	Washer	4
?	946 196 40	Door, steel construction	1
?	940 907 40	Fastener	1
?	081 282 40	Silent block	1
?	340 461 99	Washer	1
?	507 036 98	Nut	1
?	340 469 99	Washer	1
?	513 252 98	Screw	1
?	621 108 40	Pin	1
?	390 600 40	Bushing	2
?	390 601 40	Bushing	1
?	340 612 99	Washer	1
?	342 061 99	Cotter pin	1
?	350 562 99	Grease nipple	1
?	308 354 99	Bolt (standard)	4
?	501 128 98	Bolt (cold weather design)	4
?	501 688 98	Bolt (standard)	4
?	515 291 98	Bolt (cold weather design)	4
?	255 056 40	Washer	8
