PIPING - BACKHOE CYLINDER R.H. | PC4000-6 S/N 08237

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC4000-6 S/N 08237

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?		s. Hydraulic cylinder	1
?	909 353 40	Piping, assy. r.h. fig-nos. 10-38	1
?	948 428 40	Pin with plate	1
?	905 749 40	Shackle	1
?	307 886 99	Bolt	2
?	002 027 79	Lock washer	2
?	905 922 40	Clamp clip	1
?	970 524 40	Spanner	1
?	897 758 40	Half clamp	2
?	909 559 40	Weld on plate	1
?	121 674 40	Round bar steel	2
?	513 303 98	Connecting block 2	2
?	796 980 73	Pipe assy. r.h. Ш 65	1
?	769 937 73	Pipe assy. r.h. Ш 65	1
?	505 440 98	Clamp Set	6
?	534 008 99	Cover plate	3
?	509 310 98	Locking plate	1
?	504 448 98	Flange	4
?	504 449 98	Collar ring	2
?	504 461 98	Collar ring	2
?	385 243 40	Quadring	4
?	319 323 99	Bolt	8
?	308 414 99	Bolt	8
?	307 808 99	Bolt	2
?	308 613 99	Bolt	2
?	308 615 99	Bolt	4
?	334 600 99	Nut	6
?	334 601 99	Nut	2
?	340 469 99	Washer	2
?	796 981 73	Pipe assy. r.h. Ш 65	1
?	504 898 98	Flange	2
?	502 538 98	Bolt	4
?	504 662 98	Nut	4
