PC4000-6 S/N 58141

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	947 783 40	Steps	1
?	340 467 99	Washer	4
?	898 161 40	Hydraulic cylinder	1
?	896 535 40	Silent block	4
?	504 193 98	Nut	2
?	334 600 99	Nut	4
?	515 337 98	Pin	2
?	500 995 98	Washer	2
?	342 125 99	Cotter pin	2
?	897 517 40	Bearing set assy. fig-nos. 18-22	2
?	515 335 98	Dowel screw	2
?	897 543 40	Distance sleeve	2
?	501 102 98	Roller bearing	2
?	515 339 98	Shaft seal	4
?	515 336 98	Washer	2
?	514 709 98	Hose assy. DN 10x10100	1
?	374 407 99	Socket	1
?	551 987 40	Union	1
?	516 157 98	Union	1
?	954 685 40	Ladder-Guidance	1
?	510 744 98	Resilent sleeve	4
?	308 605 99	Bolt	4
?	308 631 99	Bolt	2
?	517 123 98	Washer	4
?	332 336 99	Nut	2
?	897 541 40	Plate	1
?	975 553 40	Retainer	1
?	634 423 40	Union	1
?	516 174 98	Socket	1
?	551 379 40	Union	1
?	989 538 40	Ladder-Stop	1
?	950 812 40	Reverser ball cock	1
?	951 192 40	Pipe burst valve	1
?	969 181 40	Retainer	2
?	967 399 40	Rope	1
?	958 079 40	Adapter RD30X52	1
?	518 905 98	Seal ring	1
?	501 303 98	Union	1
?	516 157 98	Socket	1
?	098 955 40	Ring	2
?	985 843 40	Chain	1
?	951 447 40	Rope clamp	1
?	519 704 98	Hose assy. DN 10x10150	1
?	519 705 98	Hose assy. DN 10X10650	1
?	319 140 99	Bolt	4
?	518 594 98	Lock washer	4
?	307 777 99	Bolt	4
?	517 122 98	Lock washer	4
?	518 133 98	Clamp Set	15
?	504 986 98	Screw	20
?	504 985 98	Locking plate	10
?	511 856 98	Cover plate	5
?	307 736 99	Bolt	10
?	519 984 98	Hose assy. DN 10x3000	1
