DISTRIBUTION POWER BUS | AFE47-GV 730E S/N A30648 - A30649 FOSKOR

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-GV 730E S/N A30648 - A30649 FOSKOR

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	SM2391	PLATE, COVER	1
?	SM2389	PLATE, COVER	1
?	WA4605	SCREW, MACHINE - #10 - 24NC X 1/2"	6
?	SM2392	PLATE, MOUNTING	1
?	SM2483	PLATE, NAME - 12 VDC	1
?	SM2482	PLATE, NAME - 24 VDC	1
?	SM2481	PLATE, NAME - GROUND	1
?	SM2998	PLATE, NAME - 24 VDC SWITCHED	1
?	TV0177	FLAT WASHER - 5/16"	16
?	SC4174	LOCKWASHER - 5/16"	16
?	PB7202	INSULATOR	8
?	SM2384	BAR, BUS	3
?	SM2388	BAR, BUS	1
?	SM2393	BRACKET, RH BUS	1
?	SM2394	BRACKET, LH BUS	1
?	MM0580	CAPSCREW - M6 X 1.00 X 14	6
?	MM0469	LOCKWASHER - M6	6
?	MM0711	FLAT WASHER - M6	6
?	PB9829	SCREW, PAN - M6 X 1.00 X 16	6
?	SM6074	PLATE, BREAKER MOUNTING	1
?	TD0794	CAPSCREW - 5/16" - 18NC X 3/4"	8
?	SM1602	SCREW, MACHINE - #6 - 32NC	36
?	SM2467	CIRCUIT BREAKER - 10 AMP 65 VDC	5
?	SM2468	BREAKER, CIRCUIT (20 AMP)	1
?	SM3188	CIRCUIT BREAKER (15 AMP)	7
?	SM3196	CIRCUIT BREAKER - 5 AMP	2
?	VC3573	CAPSCREW - 1/4" - 20NC X 1 1/4"	14
?	TR1306	CAPSCREW - 1/4" - 20NC X 1"	4
?	VN2882	JAM NUT - 1/4" - 20NC	36
?	TR1307	FLAT WASHER - 1/4"	28
?	SD2583	LOCKWASHER - 1/4"	36
?	SM2473	MAT, ARC GUARD	1
?	EM8720	CHANNEL, RUBBER	1
?	EM8719	CHANNEL, RUBBER	1
?	EG6201	GUIDE	2
?	EG6202	COVER	1
?	MM0036	CAPSCREW - M10 X 1.50 X 20	5
?	MM0471	LOCKWASHER - M10	5
?		NOTE: NS = NOT SHOWN	-1
?	EG6208	CHANNEL, RUBBER	2
?	EB7418	BAR, BUS	3
