0 |
XC3762
|
FRONT SUSPENSION ASSEMBLY |
1 |
|
|
|
|
1 |
C1602
|
CAPSCREW - 3/8" - 16NC X 1" |
2 |
|
|
|
|
2 |
C0312
|
LOCKWASHER - 3/8" |
2 |
|
|
|
|
3 |
TM9278
|
PROTECTOR |
1 |
|
|
|
|
4 |
TZ8637
|
PLUG, SENSOR |
1 |
|
|
|
|
5 |
TY8879
|
PLUG, VENT |
1 |
|
|
|
|
6 |
VN9087
|
CAPSCREW - 5/8" - 11NC X 2 1/2" |
24 |
|
|
|
|
7 |
WA0361
|
FLAT WASHER - 5/8" |
48 |
|
|
|
|
8 |
R1073
|
DRIVE SCREW - #6 - 32NC X 3/16" |
8 |
|
|
|
|
9 |
WA2892
|
PLATE, HIGH PRESSURE CYLINDER DANGER |
2 |
|
|
|
|
10 |
H2981
|
BALL, STEEL - 3/4" |
2 |
|
|
|
|
11 |
VD5076
|
GASKET (1)/(2) |
1 |
|
|
|
|
12 |
XB6467
|
HOUSING |
1 |
|
|
|
|
13 |
WA1280
|
RING, BACKUP (1) |
4 |
|
|
|
|
14 |
VN9129
|
CAPSCREW - 5/8" - 11NC X 3 3/4" |
24 |
|
|
|
|
15 |
PC1206
|
SEAL, WIPER - 13.25" (1) |
1 |
|
|
|
|
16 |
PC1204
|
SEAL, ROD DOUBLE LIP - 13.25" (1) |
1 |
|
|
|
|
17 |
PC1205
|
SEAL, ROD BUFFER - 13.25" (1) |
1 |
|
|
|
|
18 |
XC3764
|
BEARING RETAINER, LOWER |
1 |
|
|
|
|
19 |
WA0105
|
SEAL, O-RING (1) |
4 |
|
|
|
|
20 |
VW4451
|
NUT, WHEEL |
1 |
|
|
|
|
21 |
VC2629
|
PIN |
1 |
|
|
|
|
22 |
EH6529
|
STOP, PISTON |
1 |
|
|
|
|
23 |
EH6536
|
KEY, SQUARE |
1 |
|
|
|
|
24 |
XC3765
|
BEARING RETAINER, UPPER |
1 |
|
|
|
|
25 |
PC3559
|
BEARING, UPPER |
1 |
|
|
|
|
26 |
VN9096
|
CAPSCREW - 7/8" - 9NC X 2 3/4" |
12 |
|
|
|
|
27 |
WA0363
|
FLAT WASHER - 7/8" |
12 |
|
|
|
|
28 |
EH7341
|
CAP, SUSPENSION |
1 |
|
|
|
|
29 |
PC3560
|
BEARING, LOWER |
1 |
|
|
|
|
30 |
PB2194
|
CHARGING VALVE ASSEMBLY (1)/(2) |
1 |
|
|
|
|
30 |
TD7179
|
CORE, VALVE |
1 |
|
|
|
|
30 |
TR9993
|
CAP, VALVE |
1 |
|
|
|
|
30 |
TF1144
|
O-RING (VALVE BODY) |
1 |
|
|
|
|
30 |
WA0052
|
O-RING (VALVE STEM) |
1 |
|
|
|
|
31 |
XB4361
|
PISTON ASSEMBLY |
1 |
|
|
|
|
31 |
XB4362
|
PISTON |
1 |
|
|
|
|
32 |
WA0433
|
O-RING |
1 |
|
|
|
|
33 |
WA1433
|
RING, BACK-UP |
1 |
|
|
|
|
34 |
XB4363
|
PLUG, PISTON |
1 |
|
|
|
|
35 |
XB4364
|
RETAINER, RING |
3 |
|
|
|
|
36 |
XB4365
|
PLATE, RETAINER |
1 |
|
|
|
|
37 |
VM0314
|
PLUG, O-RING BOSS - 3/8" |
1 |
|
|
|
|
38 |
VN9032
|
CAPSCREW - 1/2" - 13NC X 1" |
1 |
|
|
|
|
39 |
WA0360
|
FLAT WASHER - 1/2" |
1 |
|
|
|
|
NS|46 |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
NS|47 |
VJ3911
|
OIL, SUSPENSION (5 GALLON CAN) |
4 |
|
|
|
|
NS|48 |
AK3761
|
ADDITIVE, OIL (5 GALLON CAN) |
1 |
|
|
|
|
NS|49 |
AK4942
|
NOTE: (1) INCLUDED IN AK4942 SUSPENSION SEAL KIT. |
-1 |
|
|
|
|
NS|50 |
RK1887
|
(2) INCLUDED IN RK1887 CHARGING VALVE KIT. |
-1 |
|
|
|
|
NS|51 |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
-1 |
|
|
