PC200-8M0 / PC200LC-8M0 S/N B50001 AND UP

2 1 2 6 5 6 7 11 12 10 8 11 12 9 6 5 6 4 3 4 10

#	Part Number	Partname	Quantity	Options
\|$0	2A5-30-00110	Track Roller Assembly	18	SN: B50001-UP \| : _
1	2A5-30-12110	Roller	1	SN: B50001-UP \| : _
2	22U-30-11450	Bushing	2	SN: B50001-UP \| : _
3	2A5-30-12130	Shaft	1	SN: B50001-UP \| : _
4	205-30-76260	O-ring	2	SN: B50001-UP \| : _
\|4	22U-30-00060	Floating Seal Assembly	2	SN: B50001-UP \| : _
5		Seal	2	SN: B50001-UP \| : _ \| SCC: C1
6		O-ring	2	SN: B50001-UP \| : _ \| SCC: C1
7	2A5-30-12140	Collar	1	SN: B50001-UP \| : _
8	20Y-30-16330	Plug	1	SN: B50001-UP \| : _
9	2A5-30-12150	Collar	1	SN: B50001-UP \| : _
10	20Y-30-16170	Pin	2	SN: B50001-UP \| : _
11	20Y-30-11340	Bolt	72	SN: B50001-UP \| : _
12	01643-31845	Washer	72	SN: B50001-UP \| : _

Komatsu PC200-8M0 / PC200LC-8M0 S/N B50001 AND UP parts catalog PDF

TRACK ROLLER (PC200LC-8M0) (R0200-008001) in PC200-8M0 / PC200LC-8M0 S/N B50001 AND UP. Diagram image and parts list.
