PC200-8M0 / PC200LC-8M0 S/N B50001 AND UP

? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	205-70-65682	Pin	1	SN: B50001-UP \| : _
?	20Y-70-11360	Spacer, T=0.8mm	1	SN: B50001-UP \| : _
?	206-70-45210	Spacer, T=1.5mm	3	SN: B50001-UP \| : _
?	205-70-71312	Plate	1	SN: B50001-UP \| : _
?	01010-81235	Bolt	2	SN: B50001-UP \| : _
?	01643-31232	Washer	2	SN: B50001-UP \| : _
?	20Y-70-41250	Pin	1	SN: B50001-UP \| : _
?	20Y-70-11340	Spacer, T=0.8mm	1	SN: B50001-UP \| : _
?	205-70-51530	Spacer, T=1.5mm	3	SN: B50001-UP \| : _
?	205-70-66581	Plate	1	SN: B50001-UP \| : _
?	01010-81230	Bolt	2	SN: B50001-UP \| : _
?	01643-31232	Washer	2	SN: B50001-UP \| : _

Komatsu PC200-8M0 / PC200LC-8M0 S/N B50001 AND UP parts catalog PDF

BOOM, 5200MM TOP PIN AND BOTTOM PIN, 100 HOURS LUBRICATION INTERVAL(PC200LC-8M0) (T1110-035002) in PC200-8M0 / PC200LC-8M0 S/N B50001 AND UP. Diagram image and parts list.
