PC200-8M0 / PC200LC-8M0 S/N B50001 AND UP

10 12 15 14 9 11 13 18 17 16 14 8 1 6 7 4 5 3 6 7 2

#	Part Number	Partname	Quantity	Options
\|1	723-46-29702	Valve Assembly, Control	1	SN: B50495-UP
\|1	723-46-29701	Valve Assembly, Control	1	SN: B50303-B50494 \| SCC: A2
\|1	723-46-29700	Valve Assembly, Control	1	SN: B50001-B50302 \| : _ \| SCC: A2
\|1	723-40-66701	Valve Assembly	1	SN: B50001-UP \| : _
1		Case	1	SN: B50001-UP \| : _ \| SCC: C1
2		Seat	1	SN: B50001-UP \| : _ \| SCC: C1
3		Seat	1	SN: B50001-UP \| : _ \| SCC: C1
4	708-8H-11530	Plug	1	SN: B50001-UP \| : _
5	07002-11423	O-ring	1	SN: B50001-UP \| : _
6		Seat	2	SN: B50001-UP \| : _ \| SCC: C1
7		Ball	2	SN: B50001-UP \| : _ \| SCC: C1
8		Plug	1	SN: B50001-UP \| : _ \| SCC: C1
8	723-40-66601	Valve Assembly	1	SN: B50001-UP \| : _
9		Case	1	SN: B50001-UP \| : _ \| SCC: C1
10		Seat	3	SN: B50001-UP \| : _ \| SCC: C1
11		Seat	3	SN: B50001-UP \| : _ \| SCC: C1
12		Ball	3	SN: B50001-UP \| : _ \| SCC: C1
13		Plug	1	SN: B50001-UP \| : _ \| SCC: C1
14	01252-61045	Bolt, Hexagon Socket Head	14	SN: B50001-UP \| : _
15	723-40-60101	Valve Assembly	1	SN: B50001-UP \| : _
16	07000-12020	O-ring	1	SN: B50001-UP \| : _
17	07001-02020	Ring, Back-up	1	SN: B50001-UP \| : _
18	709-25-11390	O-ring	1	SN: B50001-UP \| : _

Komatsu PC200-8M0 / PC200LC-8M0 S/N B50001 AND UP parts catalog PDF

CONTROL VALVE, 6-SPOOL, LOCK (10/19) (H0120-025010) in PC200-8M0 / PC200LC-8M0 S/N B50001 AND UP. Diagram image and parts list.
