TRAVELLING GEAR | PC4000-11 S/N 08273 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
01	906 031 40	Travelling gear assy.	1
02	500 152 98	O-ring	1
03	504 836 98	Circlip	1
04	006 389 98	Shaft seal	2
05	806 125 73	Seal ring	1
06	504 834 98	O-ring	1
07	768 162 73	Internal disk	7
08	968 524	External disk	8
09	342 569 99	Circlip	2
10	806 126 73	Cam	1
11	319 276 99	Screw	12
12	806 127 73	Housing	1
13	804 049	Seal ring	1
14	730 687 44	O-ring	1
15	973 146	Support ring	1
16	968 526	Support ring	2
17	968 525	Quadring	1
18	968 521	Piston	1
19	963 624	Spring	36
20	966 088	Spring	30
21	968 528	Support ring	2
22	968 527	Quadring	1
23	007 043 98	Shaft seal	2
24	504 833 98	O-ring	1
25	806 128 73	Seal ring	1
26	342 686 99	Circlip	1
27	501 402 98	Roller bearing	2
28	806 136 73	Drive shaft	1
29	319 285 99	Screw	6
30	768 806 73	Cover	1
31	319 297 99	Screw	47
32	806 129 73	Housing	1
33	313 267 99	Plug	9
34	339 907 99	Seal ring	10
35	313 295 99	Plug	2
36	339 897 99	Seal ring	2
37	763 676 73	Dipstick	1
38	501 954 98	Ball bearing	2
39	763 994 73	Spur wheel	1
40	342 662 99	Circlip	1
41	804 056	Sun gear	1
42	804 057	Support ring	1
43	806 984 73	Planetary carrier, assy. fig-nos: 62-66	1
44	501 532 98	Plug	2
45	339 796 99	Seal ring	2
46	307 932 99	Bolt	1
47	763 992 73	Internal geared double wheel	1
48	313 507 99	Eyebolt	1
49	804 060	Support ring	1
50	502 496 98	Roller bearing	1
51	804 061	Sun gear shaft	1
52	342 682 99	Circlip	1
53	804 062	Supporting disk	1
54	502 875 98	Ball bearing	1
55	502 203 98	O-ring	5
56	806 985 73	Planetary carrier, assy. fig-no: 67-76	1
57	504 838 98	Roller bearing	1
58	804 283 73	Support ring	1
59	804 284 73	Shaft seal	1
60	804 065	Sealing cover	1
61	307 949 99	Bolt	12
62	804 066	Planetary	3
63	342 693 99	Circlip	6
64	504 837 98	Roller bearing	3
65	342 576 99	Circlip	3
66	968 662	Support ring	1
67	504 835 98	O-ring	1
68	804 067	Centering ring	1
69	501 933 98	Circlip	1
70	804 068	Planetary, is only deliverable as set amount (=3 pieces)	3
\|$$71		Planetery is no more available seperatly	-2
71	504 839 98	Roller bearing	6
72	804 069	Stop washer	6
73	342 696 99	Circlip	6
74	804 070	Spacer	3
75	806 986 73	Planetary pin	3
76	342 675 99	Circlip	3
77	763 996 73	Plug	2
78	763 995 73	Intermediate ring	3
79	082 821	O-ring	1
80	307 754 99	Bolt	4
81	768 807 73	Cover	1
82	768 808 73	Cam	1
100	793 395 73	Repair kit brake consist of fig.nos. 02,03,04,06,07,08,09,10,12,14-24	1
\|$$85	799 338 73	Seal kit consist. of fig.nos. 05,13,25,34,36,45,55,59,67	1
\|$$86	799 339 73	Bearing kit consist. of fig.nos. 27,38,50,54,57,64,71	1
