SAA6D140E-5F S/N 536267-UP (For PC800-8E0/PC800LC-8E0/PC800SE-8E0/PC850-8E0/PC850SE-8E0)

1 2 3 8 4 5 6 5 6 6 7

#	Part Number	Partname	Quantity	Options
\|$0	6261-31-1200	Crankshaft Assembly	1	SN: 536267-UP
1		Crankshaft	1	SN: 536267-UP \| SCC: C1
2	6150-31-1130	Key	1	SN: 536267-UP
3	6210-31-1120	Gear, Crank	1	SN: 536267-UP
3	6261-21-8000	Metal Assembly	1	SN: 536267-UP
3	6261-21-8010	Main Metal Assembly, Standard	7	SN: 536267-UP
3	6261-29-8010	Main Metal Assembly, Undersize 0.25mm	7	SN: 536267-UP
3	6261-28-8010	Main Metal Assembly, Undersize 0.50mm	7	SN: 536267-UP
3	6261-27-8010	Main Metal Assembly, Undersize 0.75mm	7	SN: 536267-UP
3	6261-26-8010	Main Metal Assembly, Undersize 1.00mm	7	SN: 536267-UP
4		Metal, Upper, Standard	1	SN: 536267-UP \| SCC: C1
4		Metal, Upper, Undersize 0.25mm	1	SN: 536267-UP \| SCC: C1
4		Metal, Upper, Undersize 0.50mm	1	SN: 536267-UP \| SCC: C1
4		Metal, Upper, Undersize 0.75mm	1	SN: 536267-UP \| SCC: C1
4		Metal, Upper, Undersize 1.00mm	1	SN: 536267-UP \| SCC: C1
5		Metal, Lower, Standard	1	SN: 536267-UP \| SCC: C1
5		Metal, Lower, Undersize 0.25mm	1	SN: 536267-UP \| SCC: C1
5		Metal, Lower, Undersize 0.50mm	1	SN: 536267-UP \| SCC: C1
5		Metal, Lower, Undersize 0.75mm	1	SN: 536267-UP \| SCC: C1
5		Metal, Lower, Undersize 1.00mm	1	SN: 536267-UP \| SCC: C1
6	6210-21-8050	Thrust Metal Assembly, Standard	1	SN: 536267-UP
6	6210-29-8050	Thrust Metal Assembly, Oversize 0.25mm	1	SN: 536267-UP
6	6210-28-8050	Thrust Metal Assembly, Oversize 0.50mm	1	SN: 536267-UP
6	6210-27-8050	Thrust Metal Assembly, Oversize 0.75mm	1	SN: 536267-UP
6	6210-26-8050	Thrust Metal Assembly, Oversize 1.00mm	1	SN: 536267-UP
6		Metal, Thrust, Standard	3	SN: 536267-UP \| SCC: C1
6		Metal, Thrust, Oversize 0.25mm	3	SN: 536267-UP \| SCC: C1
6		Metal, Thrust, Oversize 0.50mm	3	SN: 536267-UP \| SCC: C1
6		Metal, Thrust, Oversize 0.75mm	3	SN: 536267-UP \| SCC: C1
6		Metal, Thrust, Oversize 1.00mm	3	SN: 536267-UP \| SCC: C1
7	04020-01228	Pin, Dowel	1	SN: 536267-UP
8	6211-31-1420	Pin	1	SN: 536267-UP

Komatsu SAA6D140E-5F S/N 536267-UP (For PC800-8E0/PC800LC-8E0/PC800SE-8E0/PC850-8E0/PC850SE-8E0) parts catalog PDF

CRANKSHAFT (#536267-) (A2310-001001) in SAA6D140E-5F S/N 536267-UP (For PC800-8E0/PC800LC-8E0/PC800SE-8E0/PC850-8E0/PC850SE-8E0). Diagram image and parts list.
