HEATER/AIR CONDITIONER (PB7742-1/PB4082-2) | AFE32-BA 830E ARCH MINERAL

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
1	VE4796	COVER ASSM (1)	1
1	VE1485	BLOWER ASSM (1)	1
2	VE0724	HOUSING - R.H. (1)	1
3	VE0725	HOUSING - L.H. (1)	1
4	VE0727	MOTOR ASSM (1)	1
5	VE0726	GASKET (1)	2
6	VE4807	WHEEL, BLOWER (1)	2
7	VS6380	CLIP (1)	2
8	VS6381	RING, INLET (1)	2
9	VS6382	RESISTOR (1)	1
10		WIRE - RED (1)/(3)	1
11		WIRE - YELLOW (1)/(3)	1
12		WIRE - ORANGE (1)/(3)	1
13	VE0720	BRACKET, MOUNTING (1)	1
14	VS6383	PAD, MOUNTING - R.H. (1)	1
15	VS6384	PAD, MOUNTING - L.H. (1)	1
16	VE7415	DIODE (1)	1
17	VE7417	NUT (1)	1
18	VE7416	SINK, HEAT (1)	1
19	VE7507	TERMALCOTE - .25 OZ. (1)	1
20	PB6214	CORE, HEATER (1)	1
21	VE4792	ELBOW - 90 DEG (1)	2
22	VE6474	FLAT WASHER (1)	1
23	VE6397	CLOSE-OUT, EVAPORATOR (1)	1
24	VE4795	DAMPER ASSM (1)	1
25	VE7512	PLATE ASSM (1)	1
26	VE6388	GROMMET (1)	1
27	VE6472	MACHINE SCREW (1)	4
28	VE4797	CASING, LEFT (1)	1
29	VS6383	PAD (1)	2
30	VS6407	CABLE, CONTROL (1)	1
31	VS6405	FILTER, FOAM (1)	1
32	VS6390	EVAPORATOR COIL ASSM (2)	1
33	VS6391	VALVE, EXPANSION (2)	1
34		TUBE (2)/(3)	4
35	VS6398	PLATE, EVAPORATOR (2)	1
36	VS6400	GROMMET, RUBBER (2)	1
37	VS6402	GROMMET, RUBBER (2)	1
38	VS6408	SWITCH, THERMOSTAT (2)	1
38	VS6406	KNOB, CONTROL (1)	1
38	VE7513	MACHINE SCREW	15
NS\|42		NOTE: (3) NOT SVCD SEPARATELY.	65535
