BODY & BODY PIVOT | AFE32-BA 830E ARCH MINERAL | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
?	TY9422	KEEPER, PLATE	4
?	VN9066	CAPSCREW - 3/4" - 10NC X 2"	4
?	C1542	LOCKWASHER - 3/4"	4
?	WA4867	CAPSCREW - 1 1/4" - 7NC X 10" (1)	2
?	TH5888	LOCKNUT - 1 1/4" - 7NC (1)	2
?	TY8819	PIN, BODY PIVOT (1)	2
?	TY9293	SHIM (1)	8
?	TY7318	GUIDE, BODY	1
?	TY5960	GUIDE, BODY	2
?	TY9406	PAD, BODY	8
?	TY9407	SHIM	70
?	TY9612	PAD, BODY	8
?	TR5445	LOCKWASHER - 1/2"	32
?	TR6643	NUT - 1/2" - 13NC	32
?	WA0471	CAPSCREW - 1/2" - 13NC X 2 1/4"	32
?	WA4728	FLAT WASHER - 1/2"	32
?		BODY (ORDER FROM FACTORY)	1
?	TY8820	BUSHING, PIVOT (1)	2
?	TY5795	CAP	2
?	C1612	CAPSCREW - 1/2" - 13NC X 1"	6
?	TY9419	BUSHING, BODY PIVOT (INNER)	2
?	TY9420	BUSHING, BODY PIVOT (OUTER)	2
?	AK7236	NOTE: (1) INCLUDED IN KIT AK7236	65535
