REAR DISC & PARKING BRAKE INSTL | AFE32-ED 830E COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE32-ED 830E COLLAHUASI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EC7881	ADAPTOR	1
?	WA0915	CAPSCREW - 3/4" - 10NC X 3 1/4" (12 POINT)	5
?	WA0362	FLAT WASHER - 3/4" (HARDENED)	13
?	TX1238	BRACKET	1
?	PB8877	DISC BRAKE ASSM (SEE INDEX)	2
?	WA4158	CAPSCREW - 7/8" - 9NC X 13"	4
?	WA0363	FLAT WASHER - 7/8" (HARDENED)	8
?	TK8634	SHIM - .010	6
?	TK8635	SHIM - .040	5
?	PB5669	BUSHING	2
?	WA0942	CAPSCREW - 3/4" - 10NC X 4"	8
?	EC7883	ADAPTOR	1
?	VN9104	CAPSCREW - 5/8" - 11NC X 3"	24
?	WA0361	FLAT WASHER - 5/8" (HARDENED)	24
?	TX0401	DISC	2
?	WA5632	CAPSCREW - 7/8" - 9NC X 11 1/4"	4
?	EC7878	SPACER	1
?	EB0611	STUD - 1" - 14UNS X 6"	24
?	WA1729	ELBOW, PLASTIC	1
?	TR1376	CAPSCREW - 1/2" - 13NC X 1 1/4"	1
?	TK5255	BAR, BUS	1
?	TG5720	CAPSCREW - 3/8" - 16NC X 1"	1
?	WA3479	ADAPTOR	1
?	WB0442	FITTING, BULKHEAD - 90 DEG	1
?	HA5574	HOSE	3
?	WB0358	FITTING, STRAIGHT ADAPTOR	1
?	WB0580	FITTING, STRAIGHT ADAPTOR	2
?	TK2272	BLOCK, JUNCTION	1
?	WA0720	FLAT WASHER - 3/8" (HARDENED)	2
?	C1602	CAPSCREW - 3/8" - 16NC X 1"	2
?	WB0508	FITTING, ELBOW - 90 DEG	1
?	DH3095	FITTING, PIPE	1
?	DC3418	NIPPLE, CLOSE	1
?	PB2306	VALVE, SHUT-OFF	1
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)	65535
