FIRE CONTROL INSTALLATION | AFE32-EZ 830E COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE32-EZ 830E COLLAHUASI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	PB3135	CARTRIDGE, EXPELLANT GAS	4
?	PB3246	ACTUATOR, PNEUMATIC	4
?	PB3136	BRACKET, EXPELLANT GAS	4
?	TR4731	CAPSCREW - 5/16" - 18NC X 1"	16
?	SC4174	LOCKWASHER - 5/16"	16
?	TD1684	NUT - 5/16" - 18NC	16
?	EB8337	BRACKET	1
?	PB3133	TANK, DRY CHEMICAL	4
?	PB3828	BRACKET, TANK	4
?	VP4693	GROMMET	1
?	HA2568	HOSE	1
?	VH9969	WELD STUD - 3/8" - 16NC X 3/4"	20
?	TC1233	NUT - 3/8" - 16NC	20
?	TC1231	LOCKWASHER - 3/8"	36
?	TR4439	CAPSCREW - 1/2" - 13NC X 7/8"	20
?	VN9907	CLAMP	15
?	DC5608	NIPPLE, CLOSE	2
?	WB0308	FITTING, TUBE	2
?	VA3169	ACTUATOR, REMOTE	2
?	PB0674	CARTRIDGE, ACTUATOR	2
?	HA0972	HOSE	2
?	WB0397	UNION	1
?	WB0272	FITTING	1
?	WB0467	ADAPTOR	2
?	HA0448	HOSE	1
?	HA1594	HOSE	1
?	TC6058	CLAMP	4
?	HA5742	HOSE	1
?	WB0266	FITTING, 90 DEG	2
?	2048889R1	TRIM (1)	1
?	VN9908	CLAMP	1
?	TG5720	CAPSCREW - 3/8" - 16NC X 1"	16
?		NOTE: (1) TRIM TO FIT AROUND INSIDE OF HOLE IN	65535
?		DECK WHERE HOSES ARE ROUTED THROUGH.	65535
