AFE32-EZ 830E COLLAHUASI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	C1613	CAPSCREW - 1/2" - 13NC X 1 1/4"	35
?	C1540	LOCKWASHER - 1/2"	43
?	WA0360	FLATWASHER - 1/2" (HARDENED)	20
?	YA1053	COVER, SURGE TANK	1
?	VG7811	LOCKNUT - 1/2" - 13NC	1
?	VC7836	FLAT WASHER - 1/2"	2
?	TY7528	PLATE, COVER	1
?	PB6877	LEVER, NUT	1
?	PB6842	HOOK, RUBBER HOOD	2
?	C1639	CAPSCREW - 5/16" - 18NC X 2"	2
?	VN9951	LOCKNUT - 5/16" - 18NC	2
?	EF4261	GRILLE FRAME	1
?	EC4150	GRILLE	2
?	TY7538	CLIP	22
?	WA3364	LOCKSCREW	22
?	EB9530	CHANNEL, RUBBER - AIR DAM	2
?	VN6450	CAPSCREW - 3/8" - 16NC X 7/8"	19
?	C1547	FLATWASHER - 3/8"	19
?	TY7535	CHANNEL, RUBBER - AIR DAM	1
?	C5542	CAPSCREW - 1 1/4" - 7NC X 3"	2
?	WA0366	FLATWASHER - 1 1/4" (HARDENED)	2
?	TY8055	PIN, PIVOT	1
?	EB8444	COVER	1
?	C1601	CAPSCREW - 3/8" - 16NC X 3/4"	4
?	C0312	LOCKWASHER - 3/8"	4
?	WA4726	FLATWASHER - 3/8" (HARDENED)	4
?	C1645	CAPSCREW - 3/4" - 10NC X 2 1/4"	6
?	C1542	LOCKWASHER - 3/4"	14
?	TY8058	PIVOT, ENGINE	1
?	VM3891	BUSHING, RUBBER	2
?	C1648	CAPSCREW - 3/4" - 10NC X 3"	8
?	WA0362	FLATWASHER - 3/4" (HARDENED)	8
?	C1527	NUT - 3/4" - 10NC	8
?	EC3738	HANDRAIL, FRONT CENTER	1
?	C1612	CAPSCREW - 1/2" - 13NC X 1"	8
?	TY8388	BLOCK, TAPPED	4
?	EC2617	PLATE, COVER	2
?	TC1231	LOCKWASHER - 3/8"	8
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4"	8
?	EC4149	GRILLE, L.H.	1
?	EC4148	GRILLE, R.H.	1
