DRIVE AXLE & MOUNTING | AFE32-EZ 830E COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE32-EZ 830E COLLAHUASI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	YA3098	HOUSING, AXLE	1
?	EC4617	ANTI-SWAY BAR (2)	1
?	VN9106	CAPSCREW - 1 1/4" - 7NC X 3"	24
?	WA0366	FLATWASHER - 1 1/4" (HARDENED)	24
?	TY4008	EYE, PIVOT (1)	1
?	TY7704	RING, COVER	2
?	TY1344	RETAINER, BEARING	2
?	TY1345	SPACER	2
?	C5764	CAPSCREW - 3/4" - 10NC X 6"	8
?	VL2993	LOCKNUT - 3/4" - 10NC	10
?	TY1346	PIN, PIVOT	1
?	PB6612	BEARING (1)	1
?	TY1343	CARRIER, BEARING (1)	1
?	TY1347	PLATE, LOCKING	1
?	EC8134	CAPSCREW - 1" - 13NC X 3 1/4" (DRILLED HEAD)	4
?	WA0364	FLATWASHER - 1" (HARDENED)	4
?	C1633	CAPSCREW - 5/8" - 11NC X 2 3/4"	3
?	C1541	LOCKWASHER - 5/8"	5
?	VL4462	WIRE, GROUND	1
?	VH9969	WELD STUD - 3/8" - 16NC X 3/4"	2
?	C0312	LOCKWASHER - 3/8"	2
?	C1521	NUT - 3/8" - 16NC	2
?	TX8110	SLEEVE	4
?	EC4615	PIN, BEARING	2
?	VN9211	CAPSCREW - 3/4" - 10NC X 7 1/2"	2
?	TY2734	SPACER	4
?	VN9351	RING, RETAINING (2)	4
?	PB0027	BEARING (2)	2
?	CE2510	CAPSCREW - 5/8" - 11NC X 3/4"	2
?	VN3270	CAPSCREW - 1 1/4" - 7NC X 5"	96
?	WA0366	FLATWASHER - 1 1/4" (HARDENED)	96
?		NOTE: (1) INCLUDED IN TY4011 PIVOT EYE ASSEMBLY.	65535
?		(2) INCLUDED IN EC5272 ANTI-SWAY BAR W/ BEARINGS ASSM.	65535
