BODY & BODY PIVOT | AFE32-EZ 830E COLLAHUASI | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
?	ED8713	RETAINER	2
?	MM0047	CAPSCREW - M10 X 1.50 X 30	16
?	C1542	LOCKWASHER - 3/4"	16
?	MM0738	CAPSCREW - M36 X 4	2
?	MM0700	LOCKNUT - M36 X 4.00	2
?	ED0569	PIN, BODY PIVOT (1)	2
?	TY9293	SHIM (1)	8
?	EF9827	GUIDE, BODY	1
?	TY5960	GUIDE, BODY	2
?	TY9406	PAD, BODY	8
?	TY9407	SHIM	70
?	TY9612	PAD, BODY	8
?	TR5445	LOCKWASHER - NO.6	32
?	TR6643	NUT - 1/2" - 13NC	34
?	WA0471	CAPSCREW - 1/2" - 13NC X 2 1/4"	32
?	WA4728	FLATWASHER - 1/2"	32
?		BODY (ORDER FROM FACTORY)	1
?	TY8820	BUSHING, PIVOT (1)	2
?	EF0745	BUSHING, BODY PIVOT - INNER	2
?	ED7962	BUSHING, BODY PIVOT - OUTER	2
?	AK3822	NOTE: (1) INCLUDED IN AK3822 BODY PIVOT PIN KIT.	65535
