1 |
EG0272
|
BAR, BUS |
1 |
|
|
|
|
2 |
CH3155
|
CABLE - 7J30 |
1 |
|
|
|
|
3 |
TD0789
|
CAPSCREW - 3/8" - 16NC X 1 3/4" |
8 |
|
|
|
|
4 |
TR4436
|
FLAT WASHER - 3/8" |
94 |
|
|
|
|
5 |
TC1231
|
LOCKWASHER - 3/8" |
85 |
|
|
|
|
6 |
TC1233
|
NUT - 3/8" - 16NC |
85 |
|
|
|
|
7 |
VC8762
|
CAPSCREW - 3/8" - 16NC X 1 1/2" |
31 |
|
|
|
|
8 |
EG0271
|
BAR, BUS |
6 |
|
|
|
|
9 |
EG0273
|
BAR, BUS |
1 |
|
|
|
|
10 |
CH3171
|
CABLE - 7J2 |
1 |
|
|
|
|
11 |
EG0275
|
BAR, BUS |
10 |
|
|
|
|
12 |
CH3172
|
CABLE - 7J8 |
1 |
|
|
|
|
13 |
EG1878
|
ANGLE BRACKET, INSULATING |
2 |
|
|
|
|
14 |
TV0177
|
FLAT WASHER - 5/16" |
6 |
|
|
|
|
15 |
SC4174
|
LOCKWASHER - 5/16" |
6 |
|
|
|
|
16 |
VC9049
|
CAPSCREW - 5/16" - 18NC X 5/8" |
4 |
|
|
|
|
17 |
EC2012
|
BRACKET, INSULATED |
2 |
|
|
|
|
18 |
TD1684
|
NUT - 5/16" - 18NC |
6 |
|
|
|
|
19 |
EG1876
|
BARRIER, ARC |
2 |
|
|
|
|
20 |
EG1877
|
BARRIER, ARC |
1 |
|
|
|
|
21 |
PB5593
|
CONTACTOR ASSEMBLY (G.F. & M.F.) |
2 |
|
|
|
|
21 |
TV3419
|
CONTACTOR (SEE INDEX) (1)/(2) |
2 |
|
|
|
|
21 |
VE3530
|
SENSOR, POSITION (SEE INDEX) |
2 |
|
|
|
|
22 |
VW6069
|
CAPSCREW, INSULATED |
4 |
|
|
|
|
23 |
VW6070
|
SHIELD |
4 |
|
|
|
|
24 |
TR3782
|
CAPSCREW - 5/16" - 18NC X 1 1/4" |
2 |
|
|
|
|
25 |
CH2572
|
CABLE - 7J4 |
1 |
|
|
|
|
26 |
CH2564
|
CABLE - 74 |
1 |
|
|
|
|
27 |
PB9229
|
REVERSER (SEE INDEX) |
1 |
|
|
|
|
28 |
MM0462
|
FLAT WASHER - M12 |
4 |
|
|
|
|
29 |
MM0472
|
LOCKWASHER - M12 |
4 |
|
|
|
|
30 |
MM0179
|
NUT - M12 X 1.75 |
4 |
|
|
|
|
31 |
CH2516
|
CABLE - 74A/FDT |
1 |
|
|
|
|
32 |
CH2578
|
CABLE - 7J14 (MFSE PANEL TO REVERSER) |
1 |
|
|
|
|
33 |
CH2579
|
CABLE - 7J13 (REVERSER TO MFSE PANEL) |
1 |
|
|
|
|
34 |
CH2580
|
CABLE - 7J3 |
1 |
|
|
|
|
35 |
CH3175
|
CABLE - 7TR9 |
1 |
|
|
|
|
36 |
CH3184
|
CABLE - 7TR9 |
1 |
|
|
|
|
37 |
EG0890
|
BAR, BUS |
1 |
|
|
|
|
38 |
VC6561
|
CAPSCREW - 1/2" - 13NC X 1 1/2" |
2 |
|
|
|
|
39 |
TR6008
|
FLAT WASHER - 1/2" |
2 |
|
|
|
|
40 |
TR5445
|
LOCKWASHER - 1/2" |
2 |
|
|
|
|
41 |
TR6643
|
NUT - 1/2" - 13NC |
2 |
|
|
|
|
42 |
CH3173
|
CABLE - 7GA1 |
1 |
|
|
|
|
43 |
CH3155
|
CABLE - 7J30 |
1 |
|
|
|
|
44 |
CH3154
|
CABLE - 7TR3A |
1 |
|
|
|
|
45 |
CH3152
|
CABLE - 7J1LS |
1 |
|
|
|
|
46 |
CH3172
|
CABLE - 7J8 |
1 |
|
|
|
|
47 |
CH3174
|
CABLE - 7J1L |
1 |
|
|
|
|
48 |
CH3185
|
CABLE - 7TR10 |
1 |
|
|
|
|
49 |
CH3169
|
CABLE - 7TR10 |
1 |
|
|
|
|
50 |
CH3150
|
CABLE - 7J1RS |
1 |
|
|
|
|
51 |
CH3170
|
CABLE - 7J1R |
1 |
|
|
|
|
52 |
EG5404
|
CONTROL CABINET ASSEMBLY |
1 |
|
|
|
|
53 |
CH2581
|
CABLE - 7J5 (REVERSER TO S3 SHUNT) |
1 |
|
|
|
|
54 |
PB9230
|
CONTACTOR, AIRLESS (SEE INDEX) |
12 |
|
|
|
|
55 |
EG0877
|
BAR, BUS |
1 |
|
|
|
|
56 |
EG0888
|
BAR, BUS |
2 |
|
|
|
|
57 |
EG0876
|
BAR, BUS |
1 |
|
|
|
|
NS|60 |
AK0941
|
NOTE: (1) CONTACTOR TIP KIT (STANDARD) |
65535 |
|
|
|
|
NS|61 |
AK0942
|
(2) CONTACTOR TIP KIT (SILVER-TIP) |
65535 |
|
|
