WB1061
|
ELBOW, REDUCING - 68 DEG |
2 |
|
|
|
|
? |
WA1075
|
CLAMP, T-BOLT - 7.81 DIAMETER |
8 |
|
|
|
|
? |
WB0677
|
CLAMP, T-BOLT - 6.69 DIAMETER |
2 |
|
|
|
|
? |
WA1067
|
CLAMP, T-BOLT - 6.81 DIAMETER |
2 |
|
|
|
|
? |
WB1060
|
ELBOW, REDUCING - 90 DEG |
2 |
|
|
|
|
? |
EG9241
|
TUBE, OUTER - R.H. |
1 |
|
|
|
|
? |
EG9243
|
TUBE, INNER - R.H. |
1 |
|
|
|
|
? |
EG9245
|
TUBE, OUTER - L.H. |
1 |
|
|
|
|
? |
EG9247
|
TUBE, INNER - L.H. |
1 |
|
|
|
|
? |
EC0415
|
ELBOW, SPECIAL - 90 DEG |
4 |
|
|
|
|
? |
WA1082
|
CLAMP, T-BOLT - 8.69 DIAMETER |
16 |
|
|
|
|
? |
PB2433
|
AIR CLEANER ASSEMBLY (SEE INDEX) |
2 |
|
|
|
|
? |
TB1406
|
GUARD, RAIN |
2 |
|
|
|
|
? |
TR4229
|
CAPSCREW - 5/8" - 11NC X 1 3/4" |
24 |
|
|
|
|
? |
TR2961
|
CAPSCREW - 5/8" - 11NC X 1" |
10 |
|
|
|
|
? |
TR9082
|
FLAT WASHER - 5/8" |
34 |
|
|
|
|
? |
VC1390
|
LOCKWASHER - 5/8" |
34 |
|
|
|
|
? |
EB0983
|
GUARD, RAIN - R.H. |
1 |
|
|
|
|
? |
EB0984
|
GUARD, RAIN - L.H. |
1 |
|
|
|
|
? |
EG9233
|
PLATE, MOUNTING |
2 |
|
|
|
|
? |
WA1602
|
END, ROD |
11 |
|
|
|
|
? |
HE5611
|
LOCKNUT - 3/8" - 16NC |
11 |
|
|
|
|
? |
VC8762
|
CAPSCREW - 3/8" - 16NC X 1 1/2" |
5 |
|
|
|
|
? |
EH0926
|
ROD, THREADED |
4 |
|
|
|
|
? |
TR4434
|
CAPSCREW - 3/8" - 16NC X 2" |
6 |
|
|
|
|
? |
WA3138
|
JAM NUT - 3/8" - 24NF |
13 |
|
|
|
|
? |
WA4473
|
CLAMP |
6 |
|
|
|
|
? |
EH0930
|
MOUNT |
1 |
|
|
|
|
? |
MM0047
|
CAPSCREW - M10 X 1.50 X 30 |
4 |
|
|
|
|
? |
MM0471
|
LOCKWASHER - M10 |
4 |
|
|
|
|
? |
MM0719
|
NUT - M10 |
4 |
|
|
|
|
? |
EG9249
|
ROD, THREADED |
1 |
|
|
|
|
? |
EH0931
|
ROD, THREADED |
1 |
|
|
|
|
? |
EH0927
|
BRACKET, MOUNTING |
1 |
|
|
|
|
? |
EH0935
|
HANGER |
1 |
|
|
|
|
? |
EF3324
|
PAD, TAPPED |
1 |
|
|
|
|
? |
MM0617
|
CAPSCREW - M12 X 1.75 X 25 |
2 |
|
|
|
|
? |
MM0462
|
FLAT WASHER - M12 |
2 |
|
|
|
|
? |
MM0472
|
LOCKWASHER - M12 |
2 |
|
|
|
|
? |
|
NOTE: NS = NOT SHOWN |
65535 |
|
|
|
|
? |
EG4047
|
BRACKET, UPRIGHT - R.H. |
1 |
|
|
|
|
? |
EG4048
|
BRACKET, UPRIGHT - L.H. |
1 |
|
|
