REAR AXLE BLOWER ASSEMBLY (EG0843) | AFE47-AD 730E SISHEN (A30095 & A30098)

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-AD 730E SISHEN (A30095 & A30098)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	PB8961	COUPLING	1
?	PB8962	COUPLING	1
?	PB8947	COUPLING	1
?	PB8948	COUPLING	1
?	EG0841	MOUNT, BLOWER MOTOR	1
?	WA7918	SQUARE KEY - 3/8" X 1 1/2"	1
?	ED7338	SHAFT	1
?	VE4739	CAPSCREW	8
?	VE4687	LOCKWASHER - 3/8"	8
?	EG0836	TUBE	1
?	VS8579	ORIFICE	1
?	C1643	CAPSCREW - 3/4" - 10NC X 1 3/4"	12
?	PB9216	BEARING, FLANGE CARTRIDGE	1
?	VN9074	CAPSCREW - 7/16" - 14NC X 2 1/4"	4
?	C5775	LOCKWASHER - 7/16"	8
?	WA0387	NUT - 7/16" - 14NC	8
?	PB9215	BEARING, FLANGE CARTRIDGE	1
?	VN9064	CAPSCREW - 7/16" - 14NC X 2"	4
?	C1614	CAPSCREW - 1/2" - 13NC X 1 1/2"	2
?	VE2287	IMPELLAR ASSEMBLY	1
?	DD5640	FLAT WASHER - 1/2"	2
?	C1540	LOCKWASHER - 1/2"	2
?	C1523	NUT - 1/2" - 13NC	4
?	VE9460	HUB	1
?	C9801	MACHINE SCREW - 5/16" - 18NC X 3/8"	1
?	WA7916	SQUARE KEY - 3/8" X 2	1
?	EG3476	COVER, INNER	1
?	MM0045	CAPSCREW - M12 X 1.75 X 40	5
?	MM0705	FLAT WASHER - M12	10
?	C1616	CAPSCREW - 1/2" - 13NC X 2"	2
?	VE9461	HOUSING, BLOWER	1
?	EG3480	COVER, OUTER	1
?	PB9424	HYDRAULIC MOTOR ASSEMBLY (SEE INDEX)	1
?	TF0521	RING	1
?	VN9583	SET SCREW - 3/8" - 16NC X 1/2"	4
?	E9975	SET SCREW - 5/16" - 18NC X 3/4"	2
?	MM0720	NUT - M12 X 1.75	10
?	MM0032	CAPSCREW - M12 X 1.75 X 30	5
