Komatsu parts book diagram for AFE47-BZ 730E S/N A30246-A30256 HAMMERSLEY IRON: CONTROL CABINET ASSEMBLY (EK3497)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	PB1006	LATCH & KEEPER SET	6
	?	MM0027	CAPSCREW - M6 X 1.00 X 25	12
	?	MM0469	LOCKWASHER - M6	36
	?	MM0459	FLAT WASHER - M6	36
	?	MM0019	CAPSCREW - M6 X 1.00 X 16	24
	?	EJ9356	CABINET, CONTROL	1
	?		(SEE FOLLOWING PAGES FOR BALANCE OF EK3497	-1
	?		CONTROL CABINET ASSEMBLY COMPONENT PARTS.)	-1

Komatsu AFE47-BZ 730E S/N A30246-A30256 HAMMERSLEY IRON parts catalog PDF

CONTROL CABINET ASSEMBLY (EK3497) (41437) in AFE47-BZ 730E S/N A30246-A30256 HAMMERSLEY IRON. Diagram image and parts list.
