31127R1
|
CAPSCREW - M6 X 12 |
22 |
|
|
|
|
? |
SM0926
|
SCREW, PANEL |
3 |
|
|
|
|
? |
SM2294
|
COVER, INNER ACCESS (1) |
1 |
|
|
|
|
? |
SM2405
|
SEAL, WINDOW (INSIDE) |
1 |
|
|
|
|
? |
SM2548
|
SEAL, DOOR |
1 |
|
|
|
|
? |
SM2271
|
FRAME, DOOR - L.H. |
1 |
|
|
|
|
? |
TV6025
|
CAPSCREW - 1/4" - 20NC X 1 1/2" |
1 |
|
|
|
|
? |
VN2882
|
JAM NUT |
1 |
|
|
|
|
? |
KD0252
|
MACHINE SCREW |
4 |
|
|
|
|
? |
SD4235
|
LOCKWASHER - 1/4" (EXTERNAL TOOTH) |
4 |
|
|
|
|
? |
SM2300
|
BUSHING, NYLON |
2 |
|
|
|
|
? |
SM2261
|
GASKET |
1 |
|
|
|
|
? |
SM2260
|
GASKET |
1 |
|
|
|
|
? |
PC0841
|
WINDOW ASSEMBLY |
1 |
|
|
|
|
? |
SM2265
|
GLASS |
1 |
|
|
|
|
? |
BF5190
|
RUN, GLASS - TOP |
1 |
|
|
|
|
? |
BF5191
|
RUN, GLASS - SIDE |
2 |
|
|
|
|
? |
BF5189
|
BOTTOM FRAME ASSEMBLY |
1 |
|
|
|
|
? |
BF5194
|
SEAL, OUTSIDE - RUBBER FLOCK |
1 |
|
|
|
|
? |
BF2744
|
COVER, SCREW |
1 |
|
|
|
|
? |
SM2406
|
SCREW, SELF-TAPING - #6 X 32NC |
22 |
|
|
|
|
? |
2048889R1
|
TRIM |
-1 |
|
|
|
|
? |
SM2255
|
HANDLE, PUSH BUTTON |
1 |
|
|
|
|
? |
SM2258
|
SPACER, DOOR HANDLE |
1 |
|
|
|
|
? |
SM2257
|
SPACER, DOOR HANDLE |
1 |
|
|
|
|
? |
SM2544
|
HINGE, DOOR |
1 |
|
|
|
|
? |
31154R1
|
CAPSCREW - M8 X 12 |
10 |
|
|
|
|
? |
SM2297
|
LATCH DOOR ASSEMBLY - L.H. |
1 |
|
|
|
|
? |
SM2263
|
LEVER, DOOR LATCH |
1 |
|
|
|
|
? |
SM2264
|
KNOB, DOOR LATCH LEVER |
2 |
|
|
|
|
? |
SM2354
|
SCREW - #10 - 24NC |
1 |
|
|
|
|
? |
SM2355
|
NUT, LOCKING - #10 - 24NC |
1 |
|
|
|
|
? |
TC1234
|
CAPSCREW - 3/8" - 16NC X 3/4" |
1 |
|
|
|
|
? |
TG9225
|
NUT, LOCKING - 3/8" |
1 |
|
|
|
|
? |
SM2744
|
INNER PANEL ASSEMBLY - L.H. |
1 |
|
|
|
|
? |
SM2738
|
PANEL, INNER - L.H. |
1 |
|
|
|
|
? |
SM5390
|
INSULATION, PANEL - L.H. |
1 |
|
|
|
|
? |
SM2740
|
WINDOW REGULATOR ASSEMBLY - L.H. |
1 |
|
|
|
|
? |
|
MOTOR - L.H. (NOT SERVICED SEPARATELY) |
1 |
|
|
|
|
? |
XA2020
|
ADAPTER, HARNESS |
1 |
|
|
|
|
? |
SM2832
|
BRACKET, WINDOW LIFT (INNER) |
1 |
|
|
|
|
? |
EL5721
|
BRACKET, WINDOW LIFT (OUTER) |
1 |
|
|
|
|
? |
SL9490
|
GROMMET |
1 |
|
|
|
|
? |
SM3010
|
HARNESS, POWER WINDOW |
1 |
|
|
|
|
? |
SM5832
|
GUIDE, WINDOW |
1 |
|
|
|
|
? |
MM0357
|
SCREW, MACHINE - M6 X 1.00 X 12 |
4 |
|
|
|
|
? |
MM0207
|
LOCKWASHER - M6 |
4 |
|
|
|
|
? |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
? |
SM2256
|
KEY, DOOR |
1 |
|
|
|
|
? |
|
NOTE: (1) INCLUDED IN SM2744 INNER PANEL ASSEMBLY. |
-1 |
|
|
|
|
? |
|
SEE ITEM 32. |
-1 |
|
|
