BRAKE VALVE SUB-ASSEMBLY - 1 (BF2463) | AFE47-CA 730E S/N A30257 & A30260 FOSCOR

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-CA 730E S/N A30257 & A30260 FOSCOR

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VE8070	COLLAR	2
?	BF2596	NUT	2
?	BF2594	PLUNGER	2
?		SEAL, WIPER (2)/(4)	2
?	VE8533	SCREW	1
?	BF2595	PACKING (4)	6
?	BF2598	RING, GLYD (4)	2
?		SPRING, PLUNGER RETURN (3)	2
?	BF2597	SEAT, SPRING	2
?	BF1862	SPOOL (1)	1
?		SLEEVE (1)	2
?		SPRING, SPOOL (3)	2
?		PLUNGER (1)	1
?		SEAL (2)/(4)	2
?		PACKING (2)/(4)	1
?	VE9418	PLUG	1
?	BF2590	WASHER	4
?		BOLT	4
?	VE9421	RETAINER, SLEEVE	1
?	BF2589	BODY, DUAL VALVE	1
?		PLUNGER (1)	1
?	EF5752	SPOOL, REGULATING (1)	1
?	VE8080	SPRING, REGULATOR (3)	2
?	BF2599	SPRING, REGULATOR (3)	2
?	BF2593	SEAT, STAGING	2
?	BF2592	PACKING (4)	2
?	BF2591	STUD	2
?		RING, BACKUP (2)/(4)	2
?		SEAL (2)/(4)	2
?		RING, BACKUP (2)/(4)	2
?	WA0019	O-RING (2)/(4)	2
?		RING, BACKUP (2)/(4)	4
?		SEAL (2)/(4)	2
?	EF3449	PLUG, ORIFICE - .045	1
?	BF1859	NOTE: (1) INCLUDED IN BF1859 SPOOL/SLEEVE KIT.	-1
?	BF1861	(2) INCLUDED IN BF1861 SEAL KIT.	-1
?	BF4645	(3) INCLUDED IN BF4645 SPRING KIT.	-1
?	BF4335	(4) INCLUDED IN BF4335 SEAL KIT.	-1
