AFE47-CA 730E S/N A30257 & A30260 FOSCOR

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	ED4418	BRACKET	1
?	TD1809	CAPSCREW - 1/4" - 20NC X 3/4"	2
?	DC3584	LOCKWASHER - 1/4"	2
?	TD1549	NUT - 1/4" - 20NC	2
?	PB6977	EQUALIZER, BATTERY	1
?	MM0342	MACHINE SCREW - M4 X .7 X 12	4
?	MM0378	LOCKWASHER - M4	4
?	VN9762	FLAT WASHER - M4	8
?	MM0372	NUT - M4	4
?	EF8484	PLATE, MOUNTING	1
?	EC0891	GASKET	1
?	TV3555	PLUG, BUTTON	4
?	EG0019	BAR, BUS	1
?	EC4403	WIRE	1
?	MM0007	CAPSCREW - M6 X 1.00 X 12	9
?	MM0459	FLAT WASHER - M6	18
?	MM0176	NUT - M6 X 1.00	9
?	MM0469	LOCKWASHER - M6	4
?	EJ5856	BAR, BUS	1
?	EC1725	SWITCH	2
?	EC1719	BAR, BUS	1
?	MM0593	CAPSCREW - M8 X 1.25 X 20	2
?	MM0460	FLAT WASHER - M8	34
?	MM0470	LOCKWASHER - M8	18
?	EC4406	WIRE	1
?	EF8481	WIRE	1
?	EC4405	WIRE	1
?	PB8460	BREAKER, CIRCUIT	1
?	HD6007	MACHINE SCREW - #10 - 24NC X 3/4"	2
?	VC5344	FLAT WASHER - #10	2
?	SD4245	LOCKWASHER - #10 (EXTERNAL TOOTH)	2
?	DF0017	NUT - #10 - 24NC	2
?	EH3983	BOX, EQUALIZER	1
?	WA3355	PLUG, BUTTON	1
?	TR8279	GROMMET, RUBBER	2
?	VW4875	PLUG, BUTTON	1
?	MM0022	CAPSCREW - M8 X 1.25 X 20	16
?	MM0177	NUT - M8 X 1.25	16
?	821197	STUD	2
?	S1357	JOINT, BALL	2
?	TV0177	FLAT WASHER - 5/16"	2
?	TR9180	NUT, JAM - 5/16" - 24NF	2
?	DD7501	NUT, LOCK - 5/16" - 24NF	2
?		NOTE: BATTERY EQUALIZER BOX IS NOT SERVICED AS AN	-1
?		ASSEMBLY. ORDER INDIVIDUAL COMPONENT PARTS.	-1

Komatsu AFE47-CA 730E S/N A30257 & A30260 FOSCOR parts catalog PDF

BATTERY EQUALIZER BOX ASSM - 5 (EJ5855) (55501) in AFE47-CA 730E S/N A30257 & A30260 FOSCOR. Diagram image and parts list.
