PANEL - STATEX III (PB8946) | AFE47-CA 730E S/N A30257 & A30260 FOSCOR

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-CA 730E S/N A30257 & A30260 FOSCOR

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	PB8946	PANEL	1
?	VE8179	BASE	1
?	VE8180	CARD GUIDE	10
?	VE8181	LATCH ASSEMBLY (DOES NOT INCLUDE ITEM #7)	2
?	VE8182	MACHINE SCREW - #6 - 40NF X 5/16"	8
?	TR5445	LOCKWASHER - 1/2"	4
?	VE8183	STRIKER	2
?	VE8178	LOCKWASHER - #6 (INTERNAL TOOTH)	8
?	VE8184	NUT - #6	4
?	VE8185	CEMENT	-1
?	VE8186	COVER - PANEL HOUSING (REAR)	1
?	VE4916	MACHINE SCREW - #10 - 32NF X 1/2"	3
?	VE8187	MACHINE SCREW - #10 - 32NC X 9/16"	2
?	VS6662	FLAT WASHER - #10	-1
?	VE4655	FLAT WASHER - #10	3
?	DC3101	LOCKWASHER - #10	-1
?	SF2755	NUT	-1
?	VE4385	CAP NUT (NYLON)	5
?	VE8188	SPRING	2
?	VE8189	LOCKWASHER - 1/4"	4
?	VE4902	NUT	4
?	BF0592	DECAL	1
?	VE8775	DECAL (CAUTION THIS PANEL CONTAINS PLUG IN ECT)	1
?	VE8776	DECAL (WARNING, POWER TO THIS PANEL MUST ECT)	1
?	VE8191	SOCKET, 210 CONTACTS	5
?	VE8192	KEY, INTERLOCK	10
?	VE8193	MACHINE SCREW - #2 - 32NC X 1/2"	10
?	VE8194	LOCKWASHER	10
?	VE8777	LABEL (SPECIFY STAMPING REQUIRED)	1
?	VE8195	PLATE, CONNECTOR	1
?	VE8196	SOCKET, 104 CONTACTS	4
?	PB2075	PIN, GUIDE	8
?	PB2076	PIN, GUIDE	8
?	VE8197	SUPPORT	1
?	VE8198	MACHINE SCREW - #6 - 40NF X 3/8"	2
?	TR5445	LOCKWASHER - 1/2"	2
?	VE5959	NUT	2
?	AK1991	CARD	1
?	BF5184	CARD	1
?	GE0455	BATTERY	1
?	AK1993	CARD	1
?	AK7945	CARD	1
?	AK1994	CARD	1
