EJ9964
|
SPINDLE HUB & BRAKE ASSEMBLY |
1 |
|
|
|
|
? |
VM0315
|
PLUG, O-RING |
1 |
|
|
|
|
? |
C1540
|
LOCKWASHER - 1/2" |
8 |
|
|
|
|
? |
C1614
|
CAPSCREW - 1/2" - 13NC X 1 1/2" |
8 |
|
|
|
|
? |
WA4795
|
SEAL, O-RING (1) |
1 |
|
|
|
|
? |
PC0005
|
BEARING CUP, SINGLE TAPERED ROLLER (1) |
1 |
|
|
|
|
? |
PB9999
|
BEARING CONE, SINGLE TAPERED ROLLER (1) |
1 |
|
|
|
|
? |
PB7454
|
GAUGE, SIGHT |
1 |
|
|
|
|
? |
SD5211
|
BUSHING |
1 |
|
|
|
|
? |
TY2134
|
RETAINER, BEARING |
1 |
|
|
|
|
? |
TH6916
|
VALVE, CHECK |
1 |
|
|
|
|
? |
H6881
|
PLUG, PIPE |
1 |
|
|
|
|
? |
TY2148
|
FLAT WASHER (HARDENED) - 1" |
6 |
|
|
|
|
? |
VM8258
|
CAPSCREW - 1" - 8NC X 3 3/4" |
18 |
|
|
|
|
? |
TY2136
|
SHIM - .014 (1) |
2 |
|
|
|
|
? |
TY2137
|
SHIM - .031 (1) |
3 |
|
|
|
|
? |
TY2135
|
SHIM - .002 (1) |
5 |
|
|
|
|
? |
EC3702
|
COVER |
1 |
|
|
|
|
? |
EH9514
|
HUB, FRONT WHEEL |
1 |
|
|
|
|
? |
TY1633
|
STUD - 1" - 14UNS X 7 1/4" |
35 |
|
|
|
|
? |
PB7362
|
DISC BRAKE ASSEMBLY (SEE INDEX) |
3 |
|
11765 |
|
|
? |
EJ9954
|
ADAPTOR, BRAKE |
1 |
|
|
|
|
? |
WA4682
|
CAPSCREW - 1" - 14NF X 14 1/2" |
18 |
|
|
|
|
? |
VN7703
|
NUT - 1" - 14NF |
18 |
|
|
|
|
? |
WA0364
|
FLAT WASHER - 1" |
30 |
|
|
|
|
? |
TX0808
|
BLEEDER, REMOTE |
1 |
|
|
|
|
? |
562-22-32290
|
PIN (1) |
2 |
|
|
|
|
? |
TF5190
|
FITTING, TUBE |
1 |
|
|
|
|
? |
WA0362
|
FLAT WASHER - 3/4" (HARDENED) |
4 |
|
|
|
|
? |
PC0003
|
BEARING CUP, SINGLE TAPERED ROLLER (1) |
1 |
|
|
|
|
? |
PB9997
|
BEARING CONE, SINGLE TAPERED ROLLER (1) |
1 |
|
|
|
|
? |
EC2056
|
SPACER, BEARING |
1 |
|
|
|
|
? |
EH9516
|
SPINDLE |
1 |
|
|
|
|
? |
WB2912
|
SEAL, O-RING (1) |
1 |
|
|
|
|
? |
PB5756
|
SEAL ASSEMBLY (1) |
1 |
|
|
|
|
? |
|
(NOT USED THIS APPLICATION) |
-1 |
|
|
|
|
? |
WA4818
|
CAPSCREW - 1 1/4" - 12NF X 4" |
30 |
|
|
|
|
? |
TY2149
|
FLAT WASHER, HARDENED - 1 1/4" |
60 |
|
|
|
|
? |
WA4510
|
CAPSCREW - 1 1/4" - 12NF X 3 1/4" |
30 |
|
|
|
|
? |
TY6050
|
DISC, BRAKE |
1 |
|
|
|
|
? |
TX0807
|
ANGLE |
1 |
|
|
|
|
? |
TH7593
|
FITTING, ELBOW |
1 |
|
|
|
|
? |
TX0805
|
TUBE, HYDRAULIC |
1 |
|
|
|
|
? |
VY8331
|
CLAMP |
1 |
|
|
|
|
? |
DC7524
|
CAPSCREW - 3/8" - 16NC X 7/8" |
1 |
|
|
|
|
? |
WA0720
|
FLAT WASHER - 3/8" (HARDENED) |
1 |
|
|
|
|
? |
C0312
|
LOCKWASHER - 3/8" |
1 |
|
|
|
|
? |
C1521
|
NUT - 3/8" - 16NC |
1 |
|
|
|
|
? |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
? |
PB6594
|
HUBODOMETER (2) |
1 |
|
|
|
|
? |
TX4849
|
PLATE, MOUNTING (2) |
1 |
|
|
|
|
? |
TC1234
|
CAPSCREW - 3/8" - 16NC X 3/4" (2) |
2 |
|
|
|
|
? |
TR4436
|
FLAT WASHER - 3/8" (2) |
2 |
|
|
|
|
? |
AK4943
|
NOTE: (1) INCLUDED IN AK4943 SPINDLE MAINTENANCE KIT. |
-1 |
|
|
|
|
? |
|
(2) OPTIONAL EQUIPMENT. |
-1 |
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
-1 |
|
|
