AFE47-Q 730E S/N 32691 ROSSING URANIUM

Komatsu parts book diagram for AFE47-Q 730E S/N 32691 ROSSING URANIUM: LIGHT ASSM (SUPER HALOGEN) - 2

? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	AK7552	UNIVERSAL HOUSING ASSM (1)/(2)/(3)	1
	?	AK1041	UNIVERSAL HOUSING ASSM (5)	1
	?	AK7575	BULB, LIGHT - 24V/65W (1)/(2)/(3)/(5)	1
	?	AK1284	BULB, LIGHT 24V/100W (4)	1
	?	AK7554	SPRING, BULB RETAINER - (MULTIPAK 10) (1)/(2)/(3)/(5)	1
	?	AK7536	LENS/REFLECTOR - RETARD (WITHOUT BULB) (1)/(5)	1
	?	AK7538	LENS/REFLECTOR - TAIL (WITHOUT BULB) (2)	1
	?	AK7534	LENS/REFLECTOR - FLOOD (WITHOUT BULB) (3)	1
	?	AK3337	LENS/REFLECTOR - FLOOD (WITHOUT BULB) (4)	1
	?	AK7556	GASKET - (MULTIPAK 10) (1)/(2)/(3)	1
	?	AK7559	BEZEL - (1)/(2)/(3)	1
	?	AK1043	BEZEL, RUBBER (5)	1
	?	AK7561	SCREWS - (MULTIPAK 30) (1)/(2)/(3)	3
	?		NOTE: (1) INCLUDED IN AK7506 RETARD - TURN/CLEARANCE	-1
	?		LIGHT ASSM	-1
	?		(2) INCLUDED IN AK7508 TAIL LIGHT ASSM	-1
	?		(3) INCLUDED IN AK7503 FLOOD (BACK-UP) LIGHT ASSM	-1
	?		(4) INCLUDED IN AK3326 FLOOD (BACK-UP) LIGHT ASSM	-1
	?		(5) INCLUDED IN AK3471 CLEARANCE LIGHT ASSM	-1

Komatsu AFE47-Q 730E S/N 32691 ROSSING URANIUM parts catalog PDF

LIGHT ASSM (SUPER HALOGEN) - 2 (55102) in AFE47-Q 730E S/N 32691 ROSSING URANIUM. Diagram image and parts list.
