HOIST CYLINDER ASSM - 1 (EF8397) | AFE47-Q 730E S/N 32691 ROSSING URANIUM

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-Q 730E S/N 32691 ROSSING URANIUM

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EF8351	CYLINDER HEAD ASSM	1
?	EC0978	HEAD, CYLINDER	1
?	ED5213	QUILL ASSM	1
?	EB8590	PLUG	2
?	TN9441	QUILL	1
?	722187	POPPET, BALL	2
?	VM2202	PLUG, VENT	1
?	VN9088	CAPSCREW - 7/8" - 9NC X 2 1/2"	20
?	WA0363	FLAT WASHER - 7/8"	20
?	WA0454	SEAL, O-RING (1)	1
?	WA1454	RING, BACK-UP (1)	1
?	EC1013	RING, SNAP (1)	1
?	VA3793	BEARING (1)	2
?	PB8616	SEAL - 10.50 (1)	1
?	TY1503	SEAL (1)	1
?	EG0467	RETAINER, BEARING	1
?	WA0878	CAPSCREW - 3/4" - 10NC X 2 1/2"	8
?	WA0362	FLAT WASHER - 3/4" (HARDENED)	8
?	PB8285	BEARING - 13.00 (1)	2
?	PB8287	BEARING - 8.38 (1)	2
?	PB8614	SEAL - 8.38 (1)	1
?	PB8619	SEAL - 13.00 (1)	1
?	EC0982	HOUSING	1
?	EC0990	TUBE - 11.75	1
?	EC0998	TUBE - 9.50	1
?	EF7982	ROD, PIVOT	1
?	PB8288	BEARING - 11.75 (1)	1
?	PB8289	SEAL, BUFFER - 11.75 (1)	1
?	PB8290	SEAL, ROD - 11.75 (1)	1
?	PB8291	ROD, WIPER - 11.75 (1)	1
?	PB8292	BEARING - 9.50 (1)	2
?	PB8293	SEAL, BUFFER - 9.50 (1)	1
?	PB8294	SEAL, ROD - 9.50 (1)	1
?	PB8295	WIPER, ROD - 9.50 (1)	1
?	PB6431	BEARING - 6.00 (1)	2
?	PB6432	SEAL, BUFFER - 6.00 (1)	1
?	PB6433	SEAL, ROD - 6.00 (1)	1
?	PB6434	WIPER, ROD - 6.00 (1)	1
?	WA2702	COVER, FLANGE HEAD (1)	1
?	H8524	CAPSCREW - 3/8" - 16NC X 5/8"	4
?	WA2704	COVER, FLANGE HEAD	1
?	C1611	CAPSCREW - 1/2" - 13NC X 3/4"	4
?	AK3730	NOTE: (1) INCLUDED IN AK3730 HOIST CYLINDER SEAL KIT.	-1
