UNLOADER VALVE ASSM (PB9977) | AFE47-Q 730E S/N 32691 ROSSING URANIUM

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-Q 730E S/N 32691 ROSSING URANIUM

6 5 22 4 16 10 3 17 1 9 18 19 8 2 20 7 12 21 13 11 14 15 30 27 28 29 28 26 27 26 31 25 24 32 32 33 33 34 35 23 24 2 1 36 37 38 39 40

#	Part Number	Partname	Quantity
1	BF2774	O-RING (2)	2
2	VE8009	PLUG	2
3		BLOCK, RELIEF (1)	1
4	BF2790	O-RING (2)	1
5	BF2789	PLUG	1
6	BF2788	SCREW	4
7		SEAT (1)	1
8		PLUNGER (1)	1
9	BF2791	O-RING (2)	1
10	VE8004	PLUG	1
11	BF2794	ORIFICE	1
12	VJ8776	PISTON	1
13		WASHER (1)	1
14	BF2776	SPRING	1
15		SPACER (1)	-1
16		SCREW, ADJUSTING	1
17	BF2780	O-RING (2)	1
18	BF2781	RING, BACK-UP	1
19	BF2782	O-RING	1
20		ADAPTOR (1)	1
21		NUT (1)	1
22		CAP, PROTECTION (1)	1
23		BLOCK, CARTRIDGE	1
24	BF2786	O-RING (2)	2
25	BF2785	PLUG	1
26	BF2799	O-RING (2)	3
27	BF2796	RING, BACK-UP (2)	4
28	BF2797	O-RING (2)	2
29	BF2798	INSERT, CARTRIDGE VALVE	1
30	BF2795	O-RING (2)	1
31	BF2800	ORIFICE	1
32	VE8003	PLUG	2
33	BF2801	O-RING (2)	2
34	BF2802	O-RING (2)	1
35	BF2810	BLOCK, CHECK	1
36		SEAT (1)	1
37	BF2812	VALVE, CHECK	1
38		SPRING (1)	1
39	BF2814	O-RING (2)	1
40	BF2815	PLUG	1
NS\|41		NOTE: (1) NOT SERVICED SEPERATELY.	-1
NS\|42	BF2803	(2) INCLUDED IN BF2803 SEAL KIT.	-1
