PANEL - AFSE - 1 (PB8838) | AFE47-FH 730E S/N A30524 NITTETSU

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-FH 730E S/N A30524 NITTETSU

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	VE5127	BOX, PANEL	1
?	VE5128	SINK, HEAT	2
?	DC3584	LOCKWASHER - 1/4"	-1
?	VE4902	NUT	16
?	C5746	CAPSCREW - 1/4" - 20NC X 3/4"	5
?	VE0299	BAR, BUS	2
?	VE5098	SUPPORT	2
?	VE4382	RECEPTACLE, LATCHING	2
?	VE4383	MACHINE SCREW - #4 - 40NF X 1/2"	4
?	VE4907	FLAT WASHER	4
?	VE4908	LOCKWASHER	4
?	VE4909	NUT	4
?	VE5132	PANEL ASSEMBLY (SEE INDEX)	1	64038
?	VE4911	HINGE	1
?	VE4912	MACHINE SCREW - #8 - 5/8"	5
?	VE4913	MACHINE SCREW - #8 - 3/4"	5
?	VE4389	SHIELD, INSULATION	1
?	VE4915	MACHINE SCREW - #8 - 18NC X 1/2"	9
?	VE2604	BAR, BUS	1
?	VE3217	BUS BAR	1
?	VE4604	FLAT WASHER	15
?	VE6320	CAPSCREW - 1/4" - 20NC X 1 1/8"	2
?	VE7202	FLAT WASHER - 1/4"	-1
?	TR1306	CAPSCREW - 1/4" - 20NC X 1"	6
?	VE0297	BAR, BUS	2
?	VE5310	BAR, BUS / SCREW	1
?	VE0302	BAR, BUS	2
?	VE0301	BAR, BUS	2
