STEERING ACCUMULATORS INSTALLATION | AFE47-FH 730E S/N A30524 NITTETSU

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-FH 730E S/N A30524 NITTETSU

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	MM0603	CAPSCREW - M10 X 1.50 X 16	4
?	MM0471	LOCKWASHER - M10	4
?	EJ7888	COVER	2
?	SG2103	GROMMET, RUBBER	2
?	PB8333	SWITCH, PRESSURE	2
?	PC1811	ACCUMULATOR ASSEMBLY (SEE INDEX)	2	60678
?	MM0093	CAPSCREW - M16 X 2.00 X 70	8
?	MM0706	FLAT WASHER - M16	16
?	MM0696	LOCKNUT - M16 X 2.00	16
?	EC3036	CLAMP, HALF	4
?	PC1118	RING, BASE	2
?	MM0071	CAPSCREW - M16 X 2.00 X 40	8
?	MM0464	FLAT WASHER - M16	16
?	EJ7766	BRACKET, BASE	2
?	WB0594	FITTING, STRAIGHT	1
?	VN9912	O-RING	2
?	DA6756	REDUCER	2
?	HA1896	HOSE	1
?	WB0517	FITTING, ELBOW - 90 DEG	1
?	HA3737	HOSE	1
?	EL0214	CLAMP	2
?	EL0220	SHIELD, HEAT	1
?	C1603	CAPSCREW - 3/8" - 16NC X 1 1/4"	12
?	WA0720	FLAT WASHER - 3/8"	12
?	C0312	LOCKWASHER - 3/8"	12
?		NOTE: NS = NOT SHOWN	-1
?	EG0008	HARNESS, ACCUMULATOR PRESSURE SWITCH	1
