0 |
EM0460
|
SPINDLE HUB & BRAKE ASSEMBLY |
1 |
|
|
|
|
1 |
VM0315
|
PLUG, O-RING BOSS - 1/2" |
1 |
|
|
|
|
2 |
C1540
|
LOCKWASHER - 1/2" |
8 |
|
|
|
|
3 |
C1614
|
CAPSCREW - 1/2" - 13NC X 1 1/2" |
8 |
|
|
|
|
4 |
WA4795
|
SEAL, O-RING (1) |
1 |
|
|
|
|
5 |
PC0005
|
BEARING CUP, SINGLE TAPERED ROLLER (1) |
1 |
|
|
|
|
6 |
PB9999
|
BEARING CONE, SINGLE TAPERED ROLLER (1) |
1 |
|
|
|
|
7 |
PB7454
|
GAUGE, SIGHT |
1 |
|
|
|
|
8 |
SD5211
|
BUSHING, PIPE |
1 |
|
|
|
|
9 |
EL9506
|
RETAINER, BEARING |
1 |
|
|
|
|
10 |
TH6916
|
VALVE, CHECK |
1 |
|
|
|
|
11 |
R2491
|
PLUG, DRAIN (MAGNETIC) |
1 |
|
|
|
|
12 |
TY2148
|
FLAT WASHER - 1" |
6 |
|
|
|
|
13 |
VM8258
|
CAPSCREW - 1" - 8NC X 3 3/4" |
18 |
|
|
|
|
14 |
EL9514
|
SHIM - 0.18 (1) |
4 |
|
|
|
|
15 |
EL9515
|
SHIM - 0.51 (1) |
5 |
|
|
|
|
16 |
EL9513
|
SHIM - 0.13 (1) |
3 |
|
|
|
|
17 |
EC3702
|
COVER |
1 |
|
|
|
|
18 |
EH9514
|
HUB, FRONT WHEEL |
1 |
|
|
|
|
19 |
TY1633
|
STUD - 1" - 14UNS X 7 1/4" |
35 |
|
|
|
|
20 |
PB7362
|
DISC BRAKE ASSEMBLY (SEE INDEX) |
3 |
|
11765 |
|
|
21 |
EJ9954
|
ADAPTER, BRAKE |
1 |
|
|
|
|
22 |
WA4682
|
CAPSCREW - 1" - 14NF X 14 1/2" |
18 |
|
|
|
|
23 |
VN7703
|
NUT - 1" - 14NF |
18 |
|
|
|
|
24 |
WA0364
|
FLAT WASHER - 1" |
30 |
|
|
|
|
25 |
TX0808
|
BLEEDER, REMOTE |
1 |
|
|
|
|
26 |
562-22-32290
|
PIN (1) |
2 |
|
|
|
|
27 |
TF5190
|
FITTING, TUBE CONNECTOR |
1 |
|
|
|
|
28 |
WA0362
|
FLAT WASHER - 3/4" |
4 |
|
|
|
|
29 |
PC0003
|
BEARING CUP, SINGLE TAPERED ROLLER (1) |
1 |
|
|
|
|
30 |
PB9997
|
BEARING CONE, SINGLE TAPERED ROLLER (1) |
1 |
|
|
|
|
31 |
EC2056
|
SPACER, BEARING |
1 |
|
|
|
|
32 |
EL9525
|
SPINDLE |
1 |
|
|
|
|
33 |
WB2912
|
SEAL, O-RING (1) |
1 |
|
|
|
|
34 |
PC2487
|
SEAL ASSEMBLY (1) |
1 |
|
|
|
|
35 |
SL5023
|
O-RING (1) |
1 |
|
|
|
|
35 |
|
(NOT USED THIS APPLICATION) |
-1 |
|
|
|
|
36 |
WA4818
|
CAPSCREW - 1 1/4" - 12NF X 4" |
30 |
|
|
|
|
37 |
TY2149
|
FLAT WASHER - 1 1/4" |
60 |
|
|
|
|
38 |
WA4510
|
CAPSCREW - 1 1/4" - 12NF X 3 1/4" |
30 |
|
|
|
|
39 |
TY6050
|
DISC, BRAKE |
1 |
|
|
|
|
40 |
TX0807
|
ANGLE |
1 |
|
|
|
|
41 |
TH7593
|
FITTING, ELBOW |
1 |
|
|
|
|
42 |
TX0805
|
TUBE, HYDRAULIC |
1 |
|
|
|
|
43 |
VY8331
|
CLAMP, VINYL - 1/4" |
1 |
|
|
|
|
44 |
DC7524
|
CAPSCREW - 3/8" - 16NC X 7/8" |
1 |
|
|
|
|
45 |
WA0720
|
FLAT WASHER - 3/8" |
1 |
|
|
|
|
46 |
C0312
|
LOCKWASHER - 3/8" |
1 |
|
|
|
|
47 |
C1521
|
NUT - 3/8" - 16NC |
1 |
|
|
|
|
NS|50 |
AK5508
|
NOTE: (1) INCLUDED IN AK5508 SPINDLE MAINTENANCE KIT. |
-1 |
|
|
|
|
NS|51 |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
-1 |
|
|
