SPINDLE, HUB AND BRAKE INSTL | AFE48-AR 930E S/N A30115 SUNCOR

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Reference
1	EG7682	HUB, WHEEL	1
2	EG7679	STUD - HEADED	50
3	ED3763	COVER	1
4	C1540	LOCKWASHER - 1/2"	12
5	C1614	CAPSCREW - 1/2" - 13NC X 1 1/2"	12
6	EH5317	O-RING (1)	1
7	ED3769	SHIM - .005 (1)	3
8	ED3770	SHIM - .007 (1)	4
9	ED3771	SHIM - .020 (1)	6
10	TY2148	FLAT WASHER - 1" (HARDENED)	8
11	VM8258	CAPSCREW - 1" - 8NC X 3 3/4" - G8	8
12	ED3767	RETAINER, BEARING	1
13	ED3768	CAP, SPINDLE	1
14	EH5322	O-RING (1)	1
15	PC0004	CUP, ROLLER (TAPERED) (1)	1
16	PB9998	CONE, ROLLER (TAPERED) (1)	1
17	EH5301	O-RING (1)	1
18	ED3755	SHIM (1)	12
19	ED4887	GEAR, SPEED SENSOR	1
20	WA0360	FLAT WASHER - 1/2" (HARDENED)	17
21	VN9095	CAPSCREW - 1/2" - 13NC X 2 3/4" - G8	12
22	VN9055	CAPSCREW - 3/8" - 16NC X 1 3/4" - G8	1
23	HE5611	LOCKNUT - 3/8" - G8	1
24	PB9889	SENSOR, SPEED	1
25	WA5659	FLAT WASHER - (HARDENED) SPECIAL	2
26	WA0961	CAPSCREW - 7/8" - 9NC X 5" (12 PNT) - G9	2
27	EG0588	MOUNT, SENSOR	1
28	EH5314	FRONT BRAKE ASSEMBLY (SEE FIG 60001)	1	60001
29	ED3775	ADAPTOR, BRAKE	1
30	TY2149	FLAT WASHER, (HARDENED)	89
31	WA5669	CAPSCREW (12 PNT)	57
32	WA5660	CAPSCREW (12 PNT)	32
33	EG7689	O-RING (1)	1
34	EH5303	O-RING (1)	1
35	PC0002	CUP-ROLLER (TAPERED) (1)	1
36	PB9996	CONE - ROLLER (TAPERED) (1)	1
37	ED3772	SPACER, BEARING	1
38	EF9317	SPINDLE	1
39	PB8964	SENSOR, SPEED - L.H. ONLY	1
40	EG1768	BRACKET, L.H. REQUIRES 2 ONLY	1
41	EG0667	HARNESS, SPEED SENSOR (PB8964) - L.H. ONLY	1
41	EG0657	HARNESS, SPEED SENSOR (PB9889)	1
42	SM2117	PLATE, NUT CONNECTOR	2
43	WA5642	MACHINE SCREW	8
44	5622232290	PIN	2
45	EG7678	SPACER, WHEEL (2)	1
46	C1622	CAPSCREW - 1/2" - 13NC X 3 1/2" (2)	5
NS\|48	AK4118	NOTE: (1) INCLUDED IN AK4118 BEARING KIT.	-1
