OPERATOR CONTROLS & OVERHEAD PANEL | AFE48-AL 930E S/N A30111 MORENCI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Reference
?	SM5319	RADIO MODULE (SEE FIG 60290)	1	60290
?	EG7491	HARNESS, CAB OVERHEAD	1
?	SM5315	WARNING LIGHTS MODULE (SEE FIG 60290)	1	60290
?	SM5316	PLM/FILTER MINDER MODULE (SEE FIG 60290) (1)	1	60290
?	EH3428	PLM/FILTER MINDER MODULE (SEE FIG 60290) (2)	1	60290
?	EF9756	HARNESS, PAYLOAD METER CAB	1
?	SM5234	CLOSURE, FRONT	1
?	PB8658	MACHINE SCREW	1
?	PB9829	SCREW, PANEL	4
?	MM0207	LOCKWASHER - M6	6
?	31127R1	CAPSCREW - M6 X 12	6
?	WB2650	CHART, GRADE SPEED	1
?	MM0347	MACHINE SCREW - M5 X .8 X 8	4
?	PB8319	LOUVER	8
?	PB8320	ADAPTOR	8
?	SM2406	SET SCREW - #6 - 32NC X 5/16"	16
?	SM2323	TRIM, EDGE	1
?	SM5273	HEATER/AIR CONDITIONER ASSM (SEE INDEX)	1	60293
?	PB9506	ELECTRONIC TREADLE - THROTTLE (SEE FIG 41060)	1	41060
?	PC0420	ELECTRONIC TREADLE - RETARDER/BRAKE (SEE FIG 60065)	1	60065
?	ED2863	RHEOSTAT, SWITCH CONTROL	1
?	SF9896	KNIFE, DISCONNECT	1
?	DL4172	SLEEVE, INSULATING	1
?	PB5957	KNOB	1
?	SM2339	SHEET METAL, FORMED	2
?	SM0926	SCREW, PANEL	10
?	SM5244	LENS, VISOR	2
?		NOTE: NS = NOT SHOWN	-1
?	SM4403	FLOOR MAT - FRONT	1
?	SM2187	FLOOR MAT - SEAT	1
?	SM2188	FLOOR MAT - REAR	1
?	1126558C1	HOLDER, DOCUMENT	1
?	31127R1	CAPSCREW - M6 X 12	4
?	SM5245	CHAIN, BEADED	1
?		NOTE: (1) EFFECTIVE WITH AFE48-AK ONLY.	-1
?		(2) EFFECTIVE WITH AFE48-AM ONLY.	-1
