1 |
VS8925
|
FRAME, MAGNET |
1 |
|
|
|
|
2 |
VS9808
|
CORE |
1 |
|
|
|
|
3 |
VJ9134
|
CAPSCREW - 3/8" - 16NC X 3/4" WITH LOCKWASHER |
2 |
|
|
|
|
4 |
GE0349
|
FRAME, SPRING BRACKET |
1 |
|
|
|
|
5 |
VE5759
|
SPRING, WITH PLUG |
1 |
|
|
|
|
6 |
VS9034
|
SCREW, ADJUSTING |
1 |
|
|
|
|
7 |
BF1890
|
ARMATURE ASSEMBLY |
1 |
|
|
|
|
8 |
C5747
|
CAPSCREW - 5/16" - 18NC X 3/4" WITH LOCKWASHER |
2 |
|
|
|
|
9 |
VE4076
|
SPRING, ARCING HORN |
1 |
|
|
|
|
10 |
VS9172
|
PIN |
1 |
|
|
|
|
11 |
VS9171
|
CLAMP |
2 |
|
|
|
|
12 |
VS9209
|
MACHINE SCREW - #10 - 32NC X 1/2" WITH LOCKWASHER |
2 |
|
|
|
|
13 |
VS8285
|
ARM, CONTACT |
1 |
|
|
|
|
14 |
VE5761
|
PIN, COTTER |
1 |
|
|
|
|
15 |
VS9175
|
SEAT, SPRING |
1 |
|
|
|
|
16 |
VM0253
|
SPRING |
1 |
|
|
|
|
17 |
BF4831
|
TIP, CONTACT |
2 |
|
|
|
|
18 |
VE5223
|
HORN, ARC |
1 |
|
|
|
|
19 |
VS7132
|
SHIELD |
1 |
|
|
|
|
20 |
VE2250
|
CAPSCREW - 5/16" - 18NC X 2 1/4" |
2 |
|
|
|
|
21 |
VE2249
|
CAPSCREW - 5/16" - 18NC X 2" |
2 |
|
|
|
|
22 |
VS9212
|
CAPSCREW - 3/8" - 16NC X 1 1/4" |
1 |
|
|
|
|
23 |
VJ8979
|
CLAMP |
1 |
|
|
|
|
24 |
VJ1124
|
SUPPORT, COIL |
1 |
|
|
|
|
25 |
VJ8710
|
FLANGE, INSULATION |
2 |
|
|
|
|
26 |
BF1891
|
FLANGE, CORE |
2 |
|
|
|
|
27 |
BF1892
|
CORE |
1 |
|
|
|
|
28 |
VS7830
|
SPACER |
1 |
|
|
|
|
29 |
BF1893
|
SUPPORT |
1 |
|
|
|
|
30 |
VE2248
|
SHIM |
1 |
|
|
|
|
31 |
GE0350
|
SHUNT |
1 |
|
|
|
|
32 |
VE3288
|
PLATE, LOCKING |
1 |
|
|
|
|
33 |
VE0252
|
WASHER, SPRING |
1 |
|
|
|
|
34 |
BF1896
|
TUBE, INSULATION |
1 |
|
|
|
|
35 |
BF0705
|
MACHINE SCREW - # 10 - 32NC X 1 1/4" |
2 |
|
|
|
|
36 |
VJ7860
|
CAPSCREW - 5/16" - 18NC |
4 |
|
|
|
|
37 |
VJ9150
|
CAPSCREW - 1/4" - 20NC X 3 1/2" |
1 |
|
|
|
|
38 |
GE0351
|
CHUTE, ARC |
1 |
|
|
|
|
39 |
GE0352
|
POLE, PIECE - R.H. |
1 |
|
|
|
|
40 |
GE0353
|
POLE, PIECE - L.H. |
1 |
|
|
|
|
40 |
GE0354
|
PIN |
1 |
|
|
|
|
41 |
GE0355
|
CHUTE, ARC - R.H. SIDE |
1 |
|
|
|
|
42 |
GE0356
|
CHUTE, ARC - L.H. SIDE |
1 |
|
|
|
|
43 |
GE0357
|
SUPPORT, ARC CHUTE |
2 |
|
|
|
|
44 |
VS6089
|
CAPSCREW - 1/4" - 20NC X 3" (ZINC PLATED) |
4 |
|
|
|
|
45 |
BF1895
|
CAPSCREW - 1/4" - 20NC X 3 1/4" |
2 |
|
|
|
|
46 |
GE0361
|
SCREW |
1 |
|
|
|
|
47 |
VM0250
|
COIL ASSEMBLY |
1 |
|
|
|
|
NS|49 |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
NS|50 |
VS6881
|
FLAT WASHER - 5/16" (BRASS) |
2 |
|
|
|
|
NS|51 |
VE5762
|
FLAT WASHER - 5/16" (NARROW) |
8 |
|
|
|
|
NS|52 |
DF3445
|
FLAT WASHER - 1/4" |
2 |
|
|
|
|
NS|53 |
VE5771
|
FLAT WASHER - #10 (EXTERNAL TOOTH) |
1 |
|
|
|
|
NS|54 |
DC3584
|
FLAT WASHER - 1/4" |
7 |
|
|
|
|
NS|55 |
VE4696
|
FLAT WASHER - 5/16" |
9 |
|
|
|
|
NS|56 |
SF2755
|
NUT - #10 |
1 |
|
|
|
|
NS|57 |
VE4347
|
NUT - 1/4" |
3 |
|
|
|
|
NS|58 |
GE0358
|
FILLER PIECE |
2 |
|
|
|
|
NS|59 |
GE0359
|
CEMENT |
-1 |
|
|
|
|
NS|60 |
GE0360
|
ADHESIVE |
-1 |
|
|
|
|
NS|61 |
VE7202
|
FLAT WASHER - 1/4" (NARROW) |
8 |
|
|
|
|
NS|62 |
VE5762
|
FLAT WASHER - 5/16" (NARROW) |
2 |
|
|
|
|
NS|63 |
GE0362
|
NUT - 1/4" (SPECIAL) |
6 |
|
|
|
|
NS|64 |
VE5013
|
NUT - 5/16" (SPECIAL) |
1 |
|
|
